High Precision Carton Box Die Cutting Machine For Packaging
High Precision Carton Box Die Cutting Machine For Packaging
Specifications
Condition :
New
Type :
Packaging Machine
Color :
Silvery
Packaging Type :
Case
MOQ :
1set
Packaging Details :
wooden case
Delivery Time :
20-30 days
Payment Terms :
TT/LC
Supply Ability :
10 sets per day
Packaging Material :
Wood
Power Source :
Electric
Other Name :
paper die cutter
Brand Name :
FINTEECH
Model Number :
FB-HT1060CE
Certification :
CE
Place of Origin :
CHINA
Description
High-Precision FB-HT1060CE Die Cutting Machine for Packaging
Product Specifications
Model FB-HT1060CE
Maximum Sheet Size 1060×760mm
Minimum Sheet Size 400×350mm
Maximum Cutting Size 1060×745mm
Minimum Width of Double Cuts 5mm
Minimum Gripper Margin 9~17mm
Cutting Rule Height 23.8mm
Inner Chase Size 1080×770mm
Stock Range Paper: 80-2000g/m², 0.1-2mm; Corrugated board: up to 4mm
Die Cutting Accuracy ≤±0.075mm
Max. Die Cutting Force 300T
Max. Working Speed 9000s/h
Max. Feeder Pile Height 1630mm (with wooden pallet)
Max. Delivery Pile Height 1480mm (with wooden pallet)
Machine Dimensions 8017×4518×2502mm (L×W×H)
Net Weight 18000kg
Main Motor Power 15KW
Total Power Required 23KW
Air Requirement Pressure: 0.6-0.7Mpa, Flow: ≥0.37m³/min
Key Features
  • Advanced feeder system for precise and consistent feeding across wide stock range (90g/m² thin paper to 1000g/m² cardboard)
  • Ultrasonic double sheet detector for scratch-free, reliable operation
  • Center-line system with quick locking device for reduced make-ready time
  • 5mm hardened cutting plate or 4+1mm sandwich plate with ±0.9mm micro adjustment
  • High-performance gripper bars with unique eccentric worm gear drive system
  • Integrated gripper edge waste removal system with conveyor belt
Product Attributes
Type Packaging Machine
Condition New
Power Source Electric
Overall Dimensions Approx. 15m×4.5m×2.2m (L×W×H)
Exporting Countries UK, Italy, Mexico, Turkey, etc.
Other Name Paper Die Cutter
Color Silvery
Packaging Material Wood
Packaging Type Case
Technical Diagrams & Views
High Precision Carton Box Die Cutting Machine For Packaging High Precision Carton Box Die Cutting Machine For Packaging High Precision Carton Box Die Cutting Machine For Packaging High Precision Carton Box Die Cutting Machine For Packaging High Precision Carton Box Die Cutting Machine For Packaging High Precision Carton Box Die Cutting Machine For Packaging
