0.5mm Fiber Reinforced Plastic Rod , FRP Core Reinforcement 0.04mm Coating Low Density
0.5mm Fiber Reinforced Plastic Rod , FRP Core Reinforcement 0.04mm Coating Low Density
Specifications
Brand Name :
Dingrong
Model Number :
Φ0.4-Φ5.0
Certification :
ISO-9001
Place of Origin :
Jiangsu China
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
5000Km/month
Delivery Time :
30days
Packaging Details :
Plywood reel or plastic reel
Product Name :
FRP strength member for fiber cable
Material :
FRP Fiber Reinforced Plastic
Function :
Strengthen
Packing :
Plywood reel or plastic reel
Diameter :
0.4mm-5.0mm
Spool length :
50.4km/reel, 25.2km/reel or customized
Appearance :
No deffets harmful use such as cracks, uneven spots, and contamination
Description

Fiber Reinforced Plastic KFRP Rod/Cable Reinforcement/KFRP(FRP) strength member

KFRP Specifications:

Property Values
Diameter of KFRP(mm) 0.5
The Thickness of coating(EAA)(mm) 0.04
Diameter of KFRP with coating (mm) 0.58
Diameter tolerance (mm) ±0.05
Non-circularity for KFRP(%) ≤5
Tensile strength (Mpa) ≥1700
Tensile modulus(Gpa) ≥50
Elongation at break (%) ≤3
Minimum bending radius(mm) 10*D
Line density (g/m) 0.34±0.05
Heat-resistant Bending Test(100℃,24h,30D) No bur, crack and break
Low-temperature Bending Test(-40℃,24h,30D) No bur, crack and break
