Light Weight Fiberglass FRP Honeycomb Sandwich Panel For Dry Freight Truck Body
Light Weight Fiberglass FRP Honeycomb Sandwich Panel For Dry Freight Truck Body
Specifications
Model NO. :
Dry truck body panel
Durability :
Won′t Crack Easily When Meet Gravel
Rinse :
Easy Rinse
Technology :
High Level
Fire Index :
Conform to The National B2 Step
Used for :
Dry Freight Truck Body, House, Container
Transport Package :
Export Standard
Trademark :
SNOWFALL
Origin :
Guangzhou, China
HS Code :
8707909000
Supply Ability :
1000 Square Meter Per Week
Usage :
Industral
Product Categories :
FRP with PP
Material :
Fiberglass
Service :
OEM
Max. Measurement :
9.5m*3m
Fuction :
Good for Anti Corrosion
Customization :
Available | Customized Request
Description
Fiberglass and PP Honeycomb Sandwich Panel
Product Overview
High-performance fiberglass reinforced plastic sandwich panels with plastic honeycomb core, manufactured using advanced German vacuum bonding technology under high pressure.
Manufacturing Process

Construction: Prefabricated fiberglass reinforced plastic sheets, high-strength woven roving, and plastic honeycomb core bonded using German vacuum technology under high pressure.

Surface Coating: Iso-phtalic-NGP based resin gelcoat, FDA approved for safety and durability.

Key Advantages
  • Superior insulation properties
  • Lightweight construction
  • High strength-to-weight ratio
  • Excellent corrosion resistance
  • Glossy, smooth surface finish
  • Easy maintenance and repair
  • Long service life
Ideal choice for modern logistics applications
Standard Specifications

Available Thickness: 15mm, 18mm, 21mm

Maximum Panel Dimensions: 10m × 3m

Light Weight Fiberglass FRP Honeycomb Sandwich Panel For Dry Freight Truck Body Light Weight Fiberglass FRP Honeycomb Sandwich Panel For Dry Freight Truck Body
Technical Performance Data
No Property Value
1 Static Strength (MPa ≥) 18
2 Elastic Modulus (MPa ≥) 1500
3 Barcol Hardness (≥) 40
4 Impact Strength (KJ/M² ≥) 50
5 Edgewise Compressive Strength (MPa ≥) 10
6 Flatwise Tension Strength (KPa ≥) 450
7 Flatwise Compression Strength (MPa ≥) 1.5
No Panel Thickness (mm) Weight (kg/m²)
1 15 7.5
2 18 8.0
3 21 8.5
