100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes
100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes
100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes
100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes
100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes
100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes
Specifications
Brand Name :
Tiangong
Model Number :
TG-002
Certification :
ISO9001, ISO14001,ISO45001
Place of Origin :
Changzhou, China
MOQ :
1
Price :
USD1000-USD3000/piece
Payment Terms :
,T/T
Supply Ability :
56000 Tons per year
Delivery Time :
30 days
Packaging Details :
Pallet
Material :
42CrMo, 18CrNiMo7-6
Production Lead time :
30 days
Machining :
CNC Rough Machining or Forged Blanks
High Light :
We supply all sizes for ZPMC crane wheels for all over the world
Heat Treatment :
Normalizing and tempering
Testing :
UT & MT
Oil Protecting :
Provided
Hardness :
as Demand
Description

Industrial gearbox precision forgings - customized solutions, weight range from 100kg to 7000kg. Our precision forged steel parts are designed to meet the stringent requirements of industrial gearbox systems, with superior strength, durability and dimensional accuracy. Forging weights range from 100kg to 7000kg, and we provide customized forging solutions for a variety of heavy-duty applications, including wind power, mining, port machinery, metallurgy and petrochemical industries.


Each forging is produced with high-quality carbon steel or alloy steel materials, such as 42CrMo, 45#, 18CrNiMo7-6 and other industry standard grades. With advanced forging equipment and precision processing capabilities, we ensure that the products have the best mechanical properties, uniform grain structure and strict tolerance control.


Item Details
Materials 20CrMnTi, 18CrNiMo7-6, 42CrMo, etc.
Forging Equipment 5-ton, 8-ton, 12-ton hydraulic hammers
Application Drive shafts for power transmission
Manufacturing Process Forging + Heat Treatment + Rough Machining
Forging Ratio ≥ 3
Delivery Condition Rough machined (Normalized + Tempered, N+T)
Testing Equipment Spectrometer, UT device, tensile tester, impact tester, metallographic microscope, outside micrometer, dial bore gauge, hardness tester
Services Forging, machining, heat treatment, packaging, local logistics, customs clearance, and sea freight. Customer-oriented, quality-focused.

主要检测设备如下:


No. Equipment
1 Spectral Composition Analyzer
2 Impact Testing Machine
3 Low-Temperature Chamber for Impact Testing
4 Ultrasonic Flaw Detector
5 Brinell Hardness Tester
6 Rockwell Hardness Tester
7 Digital Hydraulic Universal Testing Machine
8 Metallographic Microscope
9 Programmable Box-Type Furnace


100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes

Our forged gear shafts have the following material characteristics:

  • High Strength: Gear shafts must withstand torque and heavy loads without deformation.

  • Good Machinability: Ease of manufacturing and precision are essential for efficient production.

  • Low Notch Sensitivity Coefficient: Minimizes stress concentration points to prevent premature failure.

  • Excellent Heat Treatment Performance: Ensures durability, wear resistance, and fatigue strength.

  • High Wear Resistance: Gear shafts should maintain a long service life even under harsh conditions.

100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes


100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes

Steel Forging Production Process:
Raw steel ingot storage (chemical composition test) → Cutting → Heating (furnace temperature test) → Heat treatment after forging (furnace temperature test) → Discharge from furnace (blank inspection) → Machining → Inspection (UT, MT, visual dimension, hardness) → Quenching & Tempering (QT) → Inspection (UT, mechanical properties, hardness, grain size) → Final dimension inspection → Packaging and marking (steel stamp, labeling) → Warehousing and delivery.



100kg To 7000kgs Forged Gear Steels , steel disc For Industry Gearboxes


Key Features:

  • Weight Range: 100 kg to 7000 kg

  • Materials: 42CrMo, 18CrNiMo7-6, 35#, 45#, etc.

  • Forging Process: Open-die forging / Free forging

  • Machining: Rough machining as per drawings

  • Heat Treatment: Normalizing, tempering

Applications:

  • Gear shafts and gear blanks for industrial gearboxes

  • Transmission components for wind turbines and heavy machinery

  • Custom forgings for power generation and metallurgical equipment

Frequently Asked Questions (FAQ)

  1. What is your forging weight range?
    Our forgings range from 100 kg to 7000 kg.

  2. Do you provide heat treatment and machining services?
    Yes, we offer complete in-house heat treatment, rough, and finish machining services.

  3. Which industries do you serve?
    We serve wind energy, heavy equipment, port machinery, and transmission systems.

  4. What is your production lead time?

    • With stock: Around 30 days

    • Without stock: 40–45 days

  5. Where is your factory located?
    We are located in Changzhou, near Shanghai, with convenient access to Shanghai Port.

We look forward to your inquiry.
