Specifications
Brand Name :
Tiangong
Certification :
ISO9001, ISO14001,ISO45001
Place of Origin :
Changzhou, China
MOQ :
1
Price :
USD500-USD2000/piece
Payment Terms :
T/T
Supply Ability :
56000 Tons per year
Delivery Time :
30days
Packaging Details :
Pallet
Material :
42CrMo, 18CrNiMo7-6 ,4140, 40CrNiMo,37CrMnSiA , 42CrNiMo 45#,35# steel
Quality Control :
100%UT
Hardness :
Customized
Application :
Container Crane
Load Capacity :
According to materials and performance
Heat Treatment :
Normalizing and tempering
Usage :
Customized Container Crane Forged Wheels
Production Lead time :
30 days
Description

Customized Container Crane Forged Wheels, Weight Range 100–7000kg. These forged crane wheels, manufactured from high-strength alloy steel, are designed for use in heavy-duty port machinery such as gantry and container cranes. They are forged to withstand high mechanical loads and harsh environmental conditions, ensuring long service life and stable performance.


Features:

Material: Standard 40CrMo alloy steel, customizable to customer-specified
Forging Type: Open-die forging and free forging available based on design and application requirements

Heat Treatment: Annealed and tempered for enhanced mechanical properties

Machining: Supplied in rough machined or as-forged condition

Ultrasonic Testing: Conducted according to customer standards for internal soundness

Applications:

  • Gantry cranes

  • Port terminal equipment

  • Container handling cranes

  • Heavy lifting systems

  • Ship-to-shore (STS) cranes

  • Rail-mounted cranes

  • Stacker reclaimers

  • Rubber-tyred gantry (RTG) cranes

  • Bulk cargo handling equipment

  • Offshore lifting platforms

Our laboratory testing equipment includes:

Spectral Component Analyzer – for chemical composition analysis

Hydraulic Universal Testing Machine – for tensile and yield strength testing

Impact Strength Testing Machine with Cryogenic Tank – for room temperature and low-temperature impact testing

Brinell & Rockwell Hardness Testers – to assess surface and core hardness

Ultrasonic Flaw Detector – for internal defect detection (UT)

Metallurgical Microscope – for grain structure and heat treatment evaluation

Program-Controlled Box Furnace – for heat treatment simulations and metallurgical testing

Our Lab inspection equipment

1

Spectral component analyzer

2

Impact strength testing machine

3

Impact test cryogenic tank

4

Ultrasonic flaw detector

5

Brinell hardness tester

6

Rockwell hardness tester

7

Digital hydraulic universal testing machine

8

H.Metallurgical microscope

9

Program-controlled box furnace
Item Details
Product Name Customized Container Crane Forged Wheels, Weight Range 100–7000kg
Material Grades - Carbon and Alloy Steels: 42CrMo, 18CrNiMo7-6, 20CrNi2Mo, 4340, 35CrMo, 1.7225, 20CrMnTi, 20CrMnMo,45#
Forging Equipment - Hydraulic Hammers: 5T, 8T, 12T - Supports large-section open die forging
Manufacturing Process Forging → Heat Treatment → Rough Machining → Dimensional & NDT Inspection
Forging Ratio ≥ 3.0 — Ensures fine grain refinement, enhanced tensile strength, and excellent internal soundness for heavy-duty operation
Applications Precision-forged components for: - Gearbox main shafts - Thrust flanges and coupling hubs - Marine transmission and propulsion shafts - Rudder stocks and steering gear drives - Suitable for both marine and industrial mechanical systems
Delivery Conditions - N+T (Normalized + Tempered): For pre-machined rough parts
Testing & Inspection - Chemical Analysis: Optical Emission Spectrometry - Mechanical Tests: Tensile , Impact , Hardness - NDT: UT , MT - Dimensional Control: Bore dial indicators, precision micrometers
