42CrMo Forged Steel Block For Wind Power Gearbox Hydraulic Applications
42CrMo Forged Steel Block For Wind Power Gearbox Hydraulic Applications
42CrMo Forged Steel Block For Wind Power Gearbox Hydraulic Applications
42CrMo Forged Steel Block For Wind Power Gearbox Hydraulic Applications
42CrMo Forged Steel Block For Wind Power Gearbox Hydraulic Applications
42CrMo Forged Steel Block For Wind Power Gearbox Hydraulic Applications
Specifications
Brand Name :
Tiangong
Certification :
ISO9001, ISO14001,ISO45001
Place of Origin :
Changzhou, China
MOQ :
1
Price :
USD300-USD1000/piece
Payment Terms :
T/T
Supply Ability :
56000 Tons per year
Delivery Time :
30days
Packaging Details :
Pallet
Size :
Accept customization or according to drawings
Application :
Wind Power, Gearbox, and Hydraulic Applications
Section shape :
Accept customization or according to drawings
Material :
China national standard raw materials
Surface :
Anti-rust oil
Utstandard :
Customizable
Oem/Odm :
Yes
Color :
Original
Description

Our 42CrMo forged steel block is designed for high-performance use in wind turbine systems, industrial gearboxes, and hydraulic components. With excellent mechanical strength, high hardenability, and superior toughness, this alloy steel block is ideal for critical parts subjected to heavy loads and cyclic stresses. It offers reliable performance after quenching and tempering, with good machinability and resistance to fatigue and impact.

Item Details
Product Name 42CrMo Forged Steel Block for Wind Power, Gearbox, and Hydraulic Applications
Material Grade - 42CrMo alloy steel- Excellent strength, toughness, and hardenability
Forging Equipment - Hydraulic Open Die Presses: 5T, 8T, 12T- Produces uniform, high-integrity steel blocks
Forging Ratio ≥ 3.0 – Improves fatigue resistance and internal soundness under dynamic or rotating loads
Manufacturing Process Raw Material Inspection → Heating → Open Die Forging → Heat Treatment → Rough Machining → Non-Destructive Testing → Final Machining (optional) → Dimensional Inspection → Packaging
Delivery Conditions - Standard: Quenched and Tempered- Optional: Annealed, Normalized, or Semi-Machine
Applications - Gearbox foundation blocks- Wind turbine bearing housings- Hydraulic system base plates- Transmission mounting structures in power equipment
Testing & Inspection - Chemical Analysis: Optical Emission Spectrometry- Mechanical Testing: Tensile, Hardness- NDT: Ultrasonic Testing (UT), Magnetic Particle Testing (MT)- Dimensional Inspection: Full-size calibrated measurements

Key Features:

  • High tensile strength and excellent toughness

  • Good hardenability and uniform microstructure after heat treatment

  • Excellent fatigue and impact resistance under heavy load conditions

  • Available in annealed or quenched & tempered condition

  • Custom sizes and weights from 100 kg to 7 tons available on request

Application Fields:

  • Wind Power: Main bearing housings, hub connection blocks, pitch system components

  • Gearboxes: Gear block bodies, transmission support parts

  • Hydraulic Systems: Cylinder blocks, valve body bases

  • Heavy Equipment: Load-bearing structural blocks for presses, cranes, and rollers

  • General Industry: Forged base plates and pre-machined blanks for custom fabrication
