4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
Specifications
Brand Name :
FORZATEC
Model Number :
4W LED LFP-12V-15Ah Specification for lighting system
Certification :
CE&ROHS
Place of Origin :
CHINA
MOQ :
1,000
Payment Terms :
L/C, T/T
Supply Ability :
10,000 PER MONTH
Delivery Time :
20 DAYS
Packaging Details :
Carton + Pallet
Rated Voltage :
5A
Rated Current :
15Ah
PV Panel :
17V/20W
Product Size(L*W*Hmm) :
200*125*115
Package Size(L*W*Hmm) :
245*240*160
Weight(Kg) :
2.5
Description

4W LED LFP-12V-15Ah Specification for lighting system Power storage LED Lighting

Specification for lighting system
Model Number
Rated Voltage 12VDC
Rated Current 5A
Battery Capacity 15Ah
PV Panel 17V/20W
Lead Plane Product Size(L*W*Hmm) 200*125*115
Package Size(L*W*Hmm) 245*240*160
Weight(Kg) 2.5
Solar Energy Input Voltage ＜25V
Current 1.14A
Charging Volume Display 13.1V/25% 13.35V/50% 13.7/75% 14.5V/100%
Charging Voltage 14.8V±0.5V
Overcurrent Protection Current ＞5A±0.2A
High Voltage Protection ＞25V±0.5V
Low Voltage Protection ＜10V±0.5V
DC Output Voltage (10V~15.5V)±0.5V
Current (0~5A)±0.2A
Discharge Volume Display 12.5V/100% 12V/75% 11V/50% 10.5V/25%
Protection overload/over current/high voitage/low voltage
USB Output Voltage 5V
Current 750mA
Environment Working Temprrature —10℃~40℃
Working Humidity 20%~90%
Storage Temperature —10℃~40℃
Storage Humidity 10%~90%

4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel4W LED LFP-12V-15Ah Lighting System Power Storage 17V / 20W PV Panel
