Specifications
Place of Origin :
China
Brand Name :
Forsentek
Model Number :
FDSB
MOQ :
1pc
Packaging Details :
Carton
Delivery Time :
3~25 working days
Payment Terms :
T/T,Western Union or Paypal
Supply Ability :
5000pcs/month
Usage :
Weight measurement
Theory :
Strain gauge load cell
Output :
Analog Sensor
Description

Double ended shear beam load cell

Double ended shear beam load cell|Double ended load cell

Features

  • Alloy steel,double ended shear beam load cell
  • Strain gauge technology,high accuracy
  • Widely used for industrial high accuracy weighing applications

Dimensions

Double ended shear beam load cell|Double ended load cell

Double ended shear beam load cell|Double ended load cell

Specifications

Capacity 100KN 200KN 250KN
Rated output 2.0mV/V
Excitation 5-15V
Zero balance ±5% R.O.
Nonlinearity ±0.05% R.O.
Hysteresis ±0.05% R.O.
Nonrepeatability ±0.03% R.O.
Creep(30min) ±0.05% R.O.
Safe overload 150% F.S.
Ultimate overload 200% F.S.
Compensated temperature -10...+40oC
Operating temperature -20...+60oC
Temperature shift zero ±0.05% R.O./10oC
Temperature shift span ±0.05% R.O./10oC
Input resistance 750±20 ohms
Output resistance 700±5 ohms
Insulation resistance >5000M ohms
Ingress protection IP65
Material of element Alloy steel
Cable Ø5.8*6000mm
Wiring code Red--E+ Black--E- Green--S+ White--S-

Double ended beam load cell

Double ended shear beam load cell|Double ended load cell
