Specifications
Model Number :
WG1612B0
Interface :
22 Pin, 8-bit 6800/8080 MPU
Backlight :
LED
Display Type :
Graphic LCD Display
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Product Name :
Large Monochrome LCD 160x128 160128 STN T6963C Graphic LCD Library Screen
Dimensions :
129mm * 102mm * 12mm
Display Format :
160x128 Dots
Viewing Angle :
6 O'clock
Display Mode :
STN
Place of Origin :
China
Payment Terms :
T/T,L/C,Credit card,Cash
Operating Voltage :
5V
Backlight Color :
Usually Y-G or Blue or Gray
Controller :
T6963C
Packaging Details :
Tray + Inner Box + Carton
MOQ :
1 piece
Brand Name :
Formike
Supply Ability :
5000000000 pieces/year
Operating Temperature :
-20°C to 70°C
Description

Large Monochrome LCD 160x128 160128 STN T6963C Graphic LCD Library Screen

Large Monochrome 160x128 LCD 160128 TFT Display STN T6963C Graphic Library Screen

Product Specification
LCD NameLarge Monochrome LCD 160x128 160128 STN T6963C Graphic LCD Library Screen
Display Format

160*128 Dots

Module Size129.0mm×102.0mm×12.0mm
View Area101.0mm×82.0mm
Active Area92.76mmx74.20mm
Dot Size0.54mm×0.54mm
Dot Pitch0.58mm×0.58mm
ICT6963C
Interface22 Pin, 8-bit 6800 / 8080 MPU interface enabled
Driving Method 1/128 Duty, 1/12 Bias
Viewing Direction6 O’clock
Operating Temperature-20℃~+70℃
Storage Temperature-30℃~+80℃
Different series type LCD mode for you to choose
No.Part Number LCD Type Backlight ColorFont Color Background Color Voltage
1WG1612B0SBY6B-A1STN Y-G PositiveYellow Green Color Black ColorYellow Green Color5V
3WG1612B0SGW6B-A1STN Negative BlueWhite ColorWhite ColorBlue Color5V
5WG1612B0SKW6B-A1STN GREY PositiveWhite Color Black ColorGrey Color 5V


Large Monochrome 160x128 LCD 160128 TFT Display STN T6963C Graphic Library Screen
Large Monochrome 160x128 LCD 160128 TFT Display STN T6963C Graphic Library Screen
Large Monochrome 160x128 LCD 160128 TFT Display STN T6963C Graphic Library ScreenLarge Monochrome 160x128 LCD 160128 TFT Display STN T6963C Graphic Library ScreenLarge Monochrome 160x128 LCD 160128 TFT Display STN T6963C Graphic Library Screen
