176x220 ILI9225 Driver IC 2 Inch Display LCD TFT IPS With 36Pin MCU Interface

Specifications

Dimensions :

39.35mm x 50.18mm x 2.5mm

Place of Origin :

China

Product Name :

176x220 TFT ILI9225 Driver IC 2 Inch LCD Display With 36Pin MCU Interface

Color :

Color

Packaging Details :

Tray + Inner Box + Carton

Controller Ic :

ILI9225G

Operating Temperature :

-20°C to 70°C

Resolution :

176 x 220

Brand Name :

Formike

Supply Voltage :

3.2V

MOQ :

1 piece

Display Size :

2.0 inch

Interface :

36 Pin, 8/16 BIT MCU

Model Number :

KWH020ST23-F01

Viewing Angle :

6 O’clock

Payment Terms :

T/T, L/C, Credit card, Cash

Delivery Time :

In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;

Supply Ability :

5000000000 pieces/year

Display Type :

Small TFT LCD Display

Description

176x220 TFT ILI9225 Driver IC 2 Inch LCD Display With 36Pin MCU Interface

176x220 ILI9225 Driver IC 2 Inch Display LCD TFT IPS With 36Pin MCU Interface

LCD Name	176x220 TFT ILI9225 Driver IC 2 Inch LCD Display With 36Pin MCU Interface
Type	2 Inch LCD Display	Resolution	176X220
Driver IC	ILI9225G	Contrast Ratio	300:1
Outline Dimension	39.35x 50.18 x 2.50mm	Active Area(HxV mm)	31.68x39.60mm
Viewing Direction	6 O'Clock	Interface	8/16 bit MCU, 36 Pin
Backlight	3 LED In parallel	Brightness	220cd/m2
Operating Temperature	-20℃~70℃	Backlight Supply Current/Voltage	45mA, 3.2V

* KWH020ST23-F01 is a small Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 176x220 resolution TFT LCD module.

* Backlight with different brightness options from 200 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.

176x220 ILI9225 Driver IC 2 Inch Display LCD TFT IPS With 36Pin MCU Interface
