2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
Specifications
Place of Origin :
china
Brand Name :
snsc
Certification :
CE/ISO
MOQ :
1 unit
Price :
USD 6000-9000
Packaging Details :
shipped by container
Delivery Time :
30-45 Days
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
9000set/Year
Model NO. :
FD20
Lift height :
>5000mm
Condition :
New
Engine :
Japan Isuzu Engine or Xc490
Hydraulic System :
Japan Shimadzu Hydraulic System
Light :
All LED Light
Seat :
Lusury Suspension Seat
Mirror :
3 Way Wider Back Mirror
Overhead Guard :
Water Proof Overhead Guard
Transmission :
Automatic Transmission
Radiator :
Copper Radiator
Color :
Yellow/ Green/ Red
Gear :
USA Eaton Steering Gear
Fork :
1070mm
Hydraulic :
Tcm Technology
Spare Parts :
Filters and Seals
Mast Type :
2stage/3stage
Mast Lifting :
3m-6m
Transport Package :
Container Package
Specification :
2000kg load capacity
Trademark :
SNSC
Origin :
China
HS Code :
84272090
Cab Location :
Adjustable
Type :
Ordinary Combustion Forklift
Power :
Diesel Engine
Load Capacity :
1T - 5T
Fuel :
Diesel
Load center :
500mm
Customization :
Available | Customized Request
Description
SNSC fork lift truck 2ton new forklift

2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
Description:
1- Auto electric hydraulic transmission by TCM technology, just use your finger can achieve the forklift's forward and backward;
2- Japan hydraulic system, by using Shimadzu brand Valve and Pump;
3- USA Eaton steering gear;
4- LED light& Protection , with long durability time;
5- Copper Radiator, with better heat radiation;
6- Red/yellow/green and all kinds of customized colors for your reference;
7- Standard duplex mast, optional 3M-7M duplex / triplex mast;
8 - Standard China engine, optional Japan Isuzu/Mitsubishi / Yanmar engine;
9 - Optional parts: Japan ISUZU engine,Side shifter,Double front tires,Solid tire,Double air filter,Vertical exhaust,fork extension,Cab,Fork positioner.
10- Container Package Method: 2ton diesel forklift package:20GP can hold 3 units,40GP can hold 6 units.
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
Spare Parts With Delivery:
To guarantee every diesel forklift customer has a good forklift using feeling and longer using life, we send some spare parts for free with every forklift delivery, eg: filters, seal and related
In future, if customers need any spare parts, we will give reflection within 24hours, so please be relax, we will never leave our customers in anxious situation, especially spare parts.
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
SpecificationsUnitFD20
1CharacteristicsPower-diesel
2Rated Capacitykg2000
3Center of loadmm500
4Lifting heightmm3000
5Free lifting heightmm135
6Forks L×W×Hmm1070x122x40
7Tilt Forward/Backward.6/12
8Min.turning radiusmm2240
9Min.ground clearance(Mast)mm110
10Overhead guard heightmm2120
11Front overhangmm473
12PerformanceMax.traveling speed(loaded)km/h19
13Max.lifting speed(loaded/empty)mm/s470/510
14Drawback pull/Grade abilitykN/%17/20
15DimensionsOverall length (without fork)mm2570
16Overall widthmm1175
17Mast lowered heightmm1990
18Mast extended heightmm4000
19ChassisTireFront-7.00-12-12PR
20Rear-6.00-9-10PR
21Wheelbasemm1600
22Tread widthFront/Rearmm970/970
23Curb weightNone-loadkg3350
24PowertrainBatteryVoltage/CapacityV/Ah12/90
25EngineModel-XC490BPG
26Rated powerkw/r.p.m37/2650
27Rated torqueNm/r.p.m148/2000
28Cylinder amount-4
29Bore×Strokemm90x100
30 Displacement-2.54
31Fuel tankL60
32Transmission-1/1 automatic transmission
33Working pressureMPa17.5
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
Forklift Catalogue:
Diesel Forklift capacity is from 1.5 ton diesel forklift to 10 ton diesel forklift;
(FD15/FD20/FD25/FD30/FD35/FD40/FD45/FD50/FD60/FD70/FD80/FD100)
Electric Forklift capacity is from 1.5ton battery forklift to 3.5ton battery forklift;
(FB15/FB20/FB25/FB30/FB35)
LPG&Gasoline Forklift capacity is from 1.5ton LPG forklift to 3.5ton LPG forklift;
(FL15/FL20/FL25/FL30/FL35)
Wearhouse material handling equipments include Electric Pallet Truck (TB)/Electric Stacker(DB)/ Electric Reach Truck(YB)/Electric Tractor(QB).
2000kgs Diesel Forklift Truck Customized 2 Stage / 3 Stage Mast
We are china Top forklift manufacture and logistic solution supplier, with 130,000 square meters production area, 30,000 units production capacity per year,5000 sets export volume.
We have established a complete sales system which is focused on producing, developing and marketing sales and after-sale service.
Quality leading the future. Our forklift quality has won highly praised from oversea clients, you will be satisfied with them when you receive, if you have any demands, welcome to inquire us freely.
