Stacker / Pallet Truck 24V Industrial Battery Charger With High Brightness LEDs:High-Efficiency Smart Charging Solution for Industrial Power Equipment

Product Overview

Technical Specifications

Core Parameters of Model CZC7 24V/30A

Full Series Specifications

Key Product Features

1. Intelligent Charging Control for Optimal Battery Health

• Dual Charging Modes: Adapt to different battery types with precision:
  • IWUIa multi-stage charging for general lead-acid batteries, including an automatic initial charging function to activate new batteries.
  • IWUUa multi-stage charging for maintenance-free lead-acid batteries, optimizing charging efficiency and reducing water loss.
• Comprehensive Protection Against Over/Under-Charging: Electric quantity and timing control ensure full charging without overcharging or undercharging. The charger auto-shuts down after completion, extending battery cycle life.
• Balanced Charging: Equalizes cell capacity across the battery pack, preventing uneven degradation and maximizing overall performance.

2. Real-Time Monitoring and User-Friendly Design

• High-Brightness LED Indicators: Clearly display running states (charging, full, error) for quick status checks, even in dim industrial environments.
• Nixie Tube Displays: Show real-time battery voltage, charging current, capacity, and elapsed time, keeping operators informed of progress.
• Information Inquiry Function: Access the last 20 charging records to track battery performance and identify potential issues.

3. Advanced Safety and Reliability

• Multi-Layer Protection Mechanisms: Safeguard against open circuits, overloads, short circuits, and over-temperature, ensuring safe operation in harsh industrial settings.
• Temperature Compensation: Adjusts constant voltage and floating charge points based on ambient temperature (except CZC7A adjustable models), maintaining charging accuracy in varying conditions.
• Power Interruption Memory: Resumes charging automatically after power recovery, avoiding interrupted cycles and reducing manual intervention.

4. Flexible and Adaptive Performance

• Soft-Start and Time-Delay Start: Minimizes inrush current to protect both the charger and battery, enhancing durability.
• Keeping Charging Function: Maintains battery capacity at optimal levels during long idle periods, ensuring readiness for use.
• Adjustable Options (CZC7A Models): Customize charging voltage and current to match various battery specifications, offering versatility for mixed fleets of equipment.

Application Scenarios

• Electric pallet trucks and stackers in warehouses and logistics centers.
• Electric lifts and movers in manufacturing facilities.
• Electric tour cars and utility vehicles in airports, ports, and industrial parks.
• Any 24V lead-acid battery-powered industrial equipment requiring reliable, efficient charging.
