SS304 / SS316 Floating Flanged Stainless Steel Ball Valve 1/2 - 8 Inch Mounting Pad
SS304 / SS316 Floating Flanged Stainless Steel Ball Valve 1/2 - 8 Inch Mounting Pad
SS304 / SS316 Floating Flanged Stainless Steel Ball Valve 1/2 - 8 Inch Mounting Pad
SS304 / SS316 Floating Flanged Stainless Steel Ball Valve 1/2 - 8 Inch Mounting Pad
Specifications
Brand Name :
KIRI or OEM
Model Number :
Q41F
Certification :
CE;ISO
Place of Origin :
CHINA
MOQ :
1PCS
Price :
Negotiable
Payment Terms :
T/T, Western Union, PayPal, etc. 30% prepayment, 70% balance paid before shipping or against copy of BL
Supply Ability :
3000pcs/week
Delivery Time :
15~20 Days
Packaging Details :
wooden case packing or as required
Material :
WCB/201/304(CF8)/316(CF8M)
Size :
1/2"-4"
Connection :
BSPT/NPT/BSPP
Working Temperature :
-10°C to +120°C
Type :
Floating Ball Valve
Drving Mode :
lever, actuator
Description

ANSI 150LB SS304 / SS316 Floating Flanged Ball Valves 1/2" - 8 Inch Mounting Pad Ball Valves

Description:



Ball valve is a form of quarter-turn valve which uses a floating ball to control flow through it.


2PC flanged ball valves are generally slightly reduced (or standard) bore, they can be either throw-away or repairable.


1) Size: 1/2" -8“


2) Matrial: 304(CF8)/316(CF8M) / WCB


3) Sealing Material: PTFE Soft Sealing

4) Full Port

5) Blow-Out Proof Stem

6) Anti Fire

7) Medium Temp.: -20° C~+150° C

8) Suitable Medium: Water, Gas, Oil, Air and Some Corrosive Liquid

9) Design: API 608

10) Pressure-Temp Rating: ASTM B16.34

11) Face to Face: ASME B16.10

12) Flange Dimensions: ASME B16.5 RF

13) Inspection&Testing Acc: API 598


Main export markets:


•Europre markets


•Central/South America


•Middle East/Africa


•Asia

KIRI VALVE is an ISO9001 certified manufacturer of stainless steel/wcb industrial valves: Ball Valve, Check valve, Gate Valve, Globe Valve, Y-strainer, pipe fittings etc.



Specification

Item No Part Name Material
1 Body CF8M/CF8/ WCB
2 End Cap CF8M/CF8/ WCB
3 Ball SS316/SS304/SS201
4 Ball Seat PTFE
5 Bolting A193-B8/A193-B7
6 Stem SS316/SS304/SS201
7 Anti-Static SS316/SS304
8 Stem Seal-Ring PTFE/GRAFOIL
9 V-Ring Packing PTFE/GRAFOIL
10 Bushing 50%SS+50%PTFE/SS304
11 Gland SS304/SS201
12 Belleville Washer SS304/SS201
13 Stem Nut Plastic
14 Stop-Lock-Cap SS304/SS201
15 Handle Gland SS304/SS201
16 Square Washer SS304/SS201
17 Circle Washer SS304/SS201
18 Screw SS304/SS201
19 Handle Sleeve (1/2”-3”) VINYL PLASTIC
20 Handle(1/2”-3”) SS201
21 Lock Device(1/2”-3”) SS201
22 Body Gasket PTFE/SS316 SPIRAL WOUND/GRAFOIL
23 Stop Bolt SS304/SS201
24 Set Screwed(4”-6”) SS304/SS201
25 Handle(4”-6”) SS304/SS201
26 Handle Adapter(4”-6”) SS304/SS201


































Competitive Advantage:

  • Good quality can be guaranteed. KIRI VALVE is an ISO9001 ,CE certified manufacturer. All of our products must be tested before
    delivery.

    Competative price.
    Good quality at competative price will help you to win your market.

    On-time delivery.
    One stop service will improve the efficiency.

    Sincere sevice:
    We will reply you with 24 hours in working days, and will patiently answer every problem.
