ZFQ Horizontal Biomass Steam Generator
ZFQ Horizontal Biomass Steam Generator
Specifications
Brand Name :
SenDian
Model Number :
SD (3)
Certification :
CE
Place of Origin :
China
MOQ :
1 sets
Price :
Need to negotiate
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
2 Sets Week
Delivery Time :
7-15 work days
core components :
Boiler body
usage :
Industrial
structure :
Water Tube
Style :
Horizontal
output :
HOT WATER
dimension(l*w*h) :
Boiler capacity dependent
key selling points :
Automatic, Easy to Operate, Remote Monitoring, Long Service Life, High Safety Level
Material :
Carbon Steel
Description

ZFQ Horizontal Biomass Steam Generator

Products Description:

This product is highly automated,personalized design,and all programs are concentrated on a button.It is an extraordinary fool-type fuzzy control,which is convenient for every operator.

Automatic intelligent electronic control system with LCD touch display:

The operating system is under automatic control,and all operating states can be clearly seen on the LCD screen.You can observe the working status,water level status,high and low steam pressure status,water pump operation status,fault alarm status,eto.in the display screen,so that you can grasp the equipment operation status at any time and use it more safely.

High-quality components:

All pipelines and instruments are connected with seamless steel pipes or pressure-resistant copper pipes,and the electrical appliances are well-known in China,which are safe and reliable in use and luxurious in configuration.

Multiple interlocking safety protection function:

The product is equipped with pressure gauge safety valve,pressure controller and other overpressure protection devices to prevent explosion accidents caused by overpressure;At the same time,it has limit low water level protection,which willautomatically stop working when the water supply is stopped,preventing the electric heating element from being damaged or even burnt out due to dry burning.The leakage protector ensures the safety of operators and equipment.

Easy to install and use:

The products have passed strict oommissioning beforeleaving the factory.Users only need to connect the power supply and water source,and press the start button to enter the operation state of the boiler,without complicated installaton.

Scientifio design,beauiful appearance:

The cabinet scientfo design style is adopted,the intemal design structure is reasonable,and the maintenance is extremely convenient.The shell adopts CNC cuting and CNC folding one-time forming prooess,with fine workmanship; The surface of the shell is treated by high temperature plastic spraying,which is durable and beautiful.

 ZFQ0.3- 0.09-YQ ZFQ0.5- 0.09-YQ ZFQ0.7- 0.09-YQ ZFQ1.0- 0.09-YQ ZFQ1.5- 0.09-YQ ZFQ2.0- 0.09-YQ
(MPa) Rated steam pressure 0.09 0.09 0.09 0.09 0.09 0.09

(℃)

Rated steam temperature

 118 118 118 118 118 118

(℃)

Feedwater temperature

 20 20 20 20 20 20

( % )

thermal efficiency

 83.5 83.5 83.5 83.5 83.5 83.5

(Kg/h)

Particulate fuel consumption

 58.5 97.5 136.5 195 292.5 390

(KW)

Power consumption

 4 5 6 7 9 11
(V) supply voltage 220 220 380 380 380 380

(T)

Transport reference weight

 2.8 4 5.8 6.5 8.5 11
(MM) long 1800 2300 2400 2700 3400 4200
wide 1500 2100 2250 2350 2400 2400
high 2600 2800 2800 2900 2900 3000

All the above values are calculated based on the low calorific value of biomass particles 4000Kcal/Kg

The parameters are changed due to technical innovation,and the factory parameters are subject to the actual drawings!
