Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Specifications
Brand Name :
SHANAN
Model Number :
SA-AN1000
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100 set/month
Delivery Time :
15work days
Packaging Details :
Box
Alarm Mode :
Sound and Light
Detection Range :
0.1-2.0mm
Frequency :
50/60Hz
Humidity :
≤95%RH
Material :
Stainless Steel
Name :
Food Metal Detector
Power :
AC 220V
Sensitivity :
0.8mm
Size :
400*300*100mm
Type :
Industrial
Warranty :
1 Year
Weight :
8kg
Working Temperature :
0-40℃
Description
Conveyor Metal Detector for Bulk Products, Powders, and Liquids

Advanced conveyor metal detection system designed for bulk products, powders, and liquid applications across multiple industries, featuring superior sensitivity and operational efficiency.

Key Features & Advantages
  • Intuitive conversational touch screen display for easy operation and quick parameter setup
  • Advanced digital signal processing with CPU-controlled analog signal collection for enhanced sensitivity and reliability
  • Large peak digital display for convenient balance adjustment and real-time monitoring
  • Multi-frequency operation with product detection data storage for over 100 product types
  • Comprehensive metal detection record database management with USB export capability
  • Multi-level user permission settings (factory, engineer, operator)
  • Direct inverter speed control through operation interface for convenient speed adjustment
  • Visual display interface for device malfunction diagnostics and maintenance
  • Production statistics with product quantity tracking, defect counting, and operation logging
  • IP-67 certified shockproof, waterproof, and dustproof design for harsh environments
  • GFS1 and FSMA compliance support for maximum brand protection and reduced product waste
Applications

Food, pharmaceutical, chemical, rubber, plastics, aquatic products, toys, clothing, electrical, leather, knitting, printing, and other industries. Detects metal impurities including iron, non-magnetic metals, copper, aluminum, stainless steel, and other non-ferrous metals to enhance product safety.

Conveyor Metal Detector For Bulk Products Powders And Liquid Applications In Various Industries
Technical Specifications
ItemSA-990 Series
Passing Width (MM)500~1200 (customizable)
Passing Height (MM)200~1000 (customizable)
Standard Detection Sensitivity FE (ΦMM)≥0.5
Standard Detection Sensitivity NON-FE (ΦMM)≥0.8
Standard Detection Sensitivity SUS304 (ΦMM)≥1.0
Protection LevelIP67
Number of Memory Products100 kinds
Display MethodLED Screen
Operation MethodTouch Button Input
Alarm ModeAlarm stop, buzzer alarm or reject mechanism optional
Machine MaterialCarbon steel paint or stainless steel 304 (HACCP, GMP, CAS compliant)
Machine Weight≥120KG
Power SupplyAC200V±10% 50-60HZ (Customize AC110V or AC380V)
Using EnvironmentTemperature: -18°C~50°C, Relative Humidity: 30~90%
Important Notes:
1. Probe detection window and overall machine size can be customized according to customer requirements.
2. Detection sensitivity decreases with increased detection window height and width.
3. Detection sensitivity is measured with test card placed in the center of the conveyor belt through the detection channel. Actual sensitivity may vary depending on product characteristics and usage conditions.
