High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
Specifications
Brand Name :
SHANAN
Model Number :
SA-990
Certification :
CE, ISO
Place of Origin :
CHINA
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100 set/month
Delivery Time :
15work days
Packaging Details :
Box
Product name :
Food industry metal detector
Application :
Health Care Industry
Material :
304 Stainless Steel
Language :
Chinese, English, Spanish, Language can be customized
Oprate panel :
Touch screen
Tunnel height :
400 mm
Conveying speed :
18-36m/min
Tunnel width :
150 mm
Sensitivity :
High Sensitivity,Fe≥0.8mm,Non-Fe≥1.2mm,Sus≥2.0mm,0.8mm ferrous
Alarm :
Automatic Stop, sound and light alarm lamp or customized
Service time :
lifelong
Weight :
150-200kg
Warranty :
1 year
Description
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detection
Bakery Applications
This metal detector is specifically designed for bakery applications, including fresh and frozen bread and rolls, semi-baked goods, croissants, cakes, pastries, doughnuts, pancakes, dough, biscuits, cookies, crackers, tarts, and fruit pies.
Challenges in the Bakery Sector
  • Extensive processing and production increases risk of stainless steel contamination from equipment failure
  • Warm, dusty environments requiring regular cleaning of machines, conveyors, and belts
  • Maintaining product integrity after baking (detecting holes in baked bread) or missing items (packets of cookies)
  • Increasing private label manufacturing demands serving multiple retailers with diverse products
Advanced Detection Features
Faster, Better Auto-Learn
With significant improvements in signal processing, the new Auto-Learn rapidly delivers excellent detection sensitivities and provides more line uptime than ever before.
Variable Frequency Technology
SHANAN's revolutionary Variable Frequency technology optimizes detection levels across a wide range of product conditions, including wet or dry products.
Technical Specifications
ParameterValues
Pass width (mm)400 | Custom non-standard
Pass height (mm)80 | 120 | 150 | 180 | 200 | 250 | 300 | 350 | 400
Standard detection sensitivity FE(Φmm)0.5 | 0.6 | 0.7 | 0.8 | 1.0 | 1.2 | 1.5 | 2.0 | 2.5
NON-FE(Φmm)0.8 | 1.0 | 1.2 | 1.5 | 2.0 | 2.5 | 3.0 | 3.5 | 4.0
SUS304(Φmm)1.0 | 1.2 | 1.5 | 2.0 | 2.5 | 3.0 | 3.5 | 4.0 | 4.5
Belt width (mm)370 | 370 | 370 | 370 | 470 | 470 | 470 | 470 | 470
Conveyor length (mm)1330 | 1330 | 1330 | 1330 | 1700 | 1700 | 1700 | 1700 | 1700
Height from belt to ground (mm)650±50 (can be customized)
Protection levelIP66
Number of memory products100 kinds
Display methodLED D (or custom touch screen)
Operation methodTouch key input (touch optional)
Material of conveyor beltFood grade plate chain
Alarm methodAlarm shutdown, buzzer alarm or rejection mechanism optional
Belt speed28m/min constant (variable speeds for different varieties, customizable frequency conversion)
Machine materialSUS304 food grade stainless steel, compliant with HACCP, GMP, CAS standards
Mechanical size (mm)1330 * 980 * 1100 (length * width * height) non-standard customizable
Machine weightApproximately 300KG
Product Images
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
Model SA-990 Specifications
ParameterSpecification
ModelSA-990
Machine length (mm)1330~2000 (customizable)
Detection tunnel width (mm)200~1200 (customizable)
Detection tunnel height (mm)50~1000 (customizable)
Standard detection sensitivity FE(Φmm)≥0.5
NON-FE(Φmm)≥0.8
SUS304(Φmm)≥1.0
Protection levelIP67
Number of memory products200+ kinds
Display modeTouch Screen
Operation modeTouch button input
Alarm modeAlarm stop, buzzer alarm or rejector device optional
Machine materialStainless steel 304, compliant with HACCP, GMP, FDA, CAS standards
Conveyor belt materialFood grade PVC or PU belt
Machine weightApproximately 280KG
Motor90~370W
Transfer speed10-28m/min (optional and adjustable)
Power supplyAC220V±10%, 50-60HZ (Customize AC110V or AC380V)
Belt height above ground (mm)700+100 (customizable)
Maximum load (single piece)10~50KG (customizable)
Using environmentTemperature: -15℃~40℃, relative humidity: 30~85%
High Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat DetectorHigh Quality Industry Conveyor Metal Detector For Food Grade Bakery Beef Meat Detector
