Specifications
Brand Name :
SHANAN
Model Number :
SACW500
Certification :
ce
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C,D/A,D/P,T/T
Packaging Details :
wooden box
Operating Temperature :
0-40℃
Power Supply :
AC 220V/50Hz
Weighing Range :
Customized
Belt Material :
Food Grade PVC Or PU
Sortting Manner :
Muti Sorting
Alarm :
Light And Sound
Display :
D
Throughout :
100~700PCS/min
Description
Automatic Conveyor Belt Industrial Checkweighers
Precision checkweighers designed to prevent fill variation in products with automated weight verification on conveyor systems.
Automatic Conveyor Belt Industrial Checkweighers Prevent Fill Variation In Products Automatic Conveyor Belt Industrial Checkweighers Prevent Fill Variation In Products Automatic Conveyor Belt Industrial Checkweighers Prevent Fill Variation In Products Automatic Conveyor Belt Industrial Checkweighers Prevent Fill Variation In Products Automatic Conveyor Belt Industrial Checkweighers Prevent Fill Variation In Products
Technical Specifications
Product Model SACW-120A
Transfer Speed 20~60 m/min
Power Supply AC220V±10% 50HZ (60HZ)
Maximum Speed 180 pcs/min
Rated Power 0.15KW
Weighing Conveyor Belt Size 250mm(L) * 120mm(W)
Single Weighing Range 1.5-200g
Elimination Method Blow-out
Weighing Accuracy Range ±0.05g~±0.1g
Control System High speed A/D sampling controller
Minimum Scale 0.01g
Preset Product Number 2000 pcs
Inspection Item Size Length: 30-150mm, Width: 30-90mm, Height: 10-100mm
Machine Size 900mm(L) * 500mm(W) * 1250mm(H)
Operation Direction Facing the machine, left to right
External Air Supply 0.6-1Mpa
Air Pressure Interface Φ8mm
Working Environment Temperature: 0°C~40°C, Humidity: 30%~95%
Body Material Stainless steel 304 polished
Operation Screen Display Chinese, English, Turkish, Spanish, etc.
Other Standard Equipment Windshield (colorless and transparent), calibration weight
Height of Belt Surface from Ground 650mm-750mm (can be customized)
Protection Level Protection level conforms to IP-55 international standard
Key Features
  • High-speed automatic weight verification
  • Precision blow-out rejection system
  • Multi-language operation interface
  • Stainless steel construction for durability
  • IP-55 protection rating for industrial environments
  • Customizable height and configuration options
Note: According to the different dimensions of the tested product and the working environment in which the equipment is running, the accuracy of the speedometer is slightly different.
