Specifications
Brand Name :
SHANAN
Model Number :
SA-4025
Place of Origin :
CHINA
Certification :
ce
Packaging Details :
wooden box
Body Material :
Mirror Polish SUS304
Parameter Settings :
Self-learning / Manual Adjustment
Inspection Speed :
Up To 600 Products Per Minute
Operation Method :
Touch Screen Operation
Warranty :
1 Year
Maximum Product Size :
600mm (W) X 400mm (H)
Power Supply :
AC 220V, 50Hz, 1.5kW
Protection Level :
IP67
Description
Food Industry X-Ray Inspection Machine
Advanced X-ray inspection system specifically designed for detecting foreign objects in aluminum foil pouches and canned goods, ensuring food safety and quality control.
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
Technical Specifications
Model SAXR-4025
X-ray source VJX IXS100 150W/210W 80kV
Detect maximum width 250 mm (customizable)
Detect maximum height 400 mm (customizable)
Best detection accuracy - FE ≥0.4 Φmm
Best detection accuracy - Glass ball ≥1.0 Φmm
Best detection accuracy - Ceramic ball ≥1.0 Φmm
Overall equipment size 1650*530*1895 mm
Detector DT X-Scan C 0.4 mm
Conveyor belt 10-60 m/min speed adjustable
Display 17-inch full-color touch screen
Maximum load-bearing capacity 5 Kg
Operating system Windows 11
Working environment Temperature: 0-40°C, Humidity: 30-90% (no condensation)
X-ray leak < 1 microsievert/hour
Exclude organizations (optional) Swing bar/Push plate removal/Flip plate/Blow
Protection method Removable protective curtain/shield
Equipment fixation and mobility Adjustable feet, standalone rejection device compatible
Power supply AC 220V
Protection level IP65
Body material SUS304
Product Gallery
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
Company Profile
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
Factory Display
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
Our Advantages
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
Packing and Shipping
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
Frequently Asked Questions
Food Industry X-Ray Inspection Machine For Aluminum Foil Pouches And Canned Goods Foreign Object Detection
