Low Attenuation HD P8 Outdoor Advertising LED Panel For Stage 1.5 mm Thicknes
Low Attenuation HD P8 Outdoor Advertising LED Panel For Stage 1.5 mm Thicknes
Specifications
Brand Name :
Onumen
Model Number :
OM-F-7P8-N
Certification :
TUV.FCC.CE.ROHS
Place of Origin :
SHENZHEN
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
3000//Square Meter/M
Delivery Time :
25Days
Packaging Details :
Wooden case or flight case as customer's request
Pixel pitch :
7.8mm
Pixel configur :
1R1G1B
Module resolution :
32*32 pixels
Module size :
250*250mm
Module quantity :
16pcs
Brightness :
1500cd/m²
Life time :
10000Hrs
Control system :
BSTAR
Color :
Black
Description

Low Attenuation HD P8 Outdoor Advertising LED Panel For Stage 1.5 mm Thicknes​

P7.8 Outdoor Led Display Features :

Outdoor advertising hd full color rgb led screen cabinet

• Waterproof metal cabinet, standard thickness 1.5 mm, easy installation for outdoor fixed

requirement.


• High gray scale, high refresh rate and high contrast ensure delicate images.


• High brightness assures images clear and vivid even if under glaring sunlight, low attenuation

and all weather defense.


• Full-depth color and brightness calibration in the factory to realize a uniform display picture on-site.


• Excellent cooling effect, operating without any noise.

Technical Specification


Item Technical Specification
Pixel Pixel pitch:7.8mm
Pixel configuration: 1R1G1B
Brightness: Red: 1000mcd Green: 2300mcd Blue: 600mcd
Wave length: Red: 625±2nm Green: 525±2nm Blue: 470±2nm
Module resolution: 32*32 pixels
Module Module size: 250mmx250mm
Cabinet size: 250mm×250mm×23mm
Cabinet Cabinet resolution: 9216 pixels
Cabinet material: 27778 pixels / sqm
Gross weight: 12kg / sqm
Module quantity: 16 pcs= 4(w) x 6(h)
Power consumption : Max.:180W/m² Everage: 90W/m²
Screen Drive method: 1/16 scanning
Brightness: 4000cd/m²
IC driver: MBI 5026
Density: 10000 pixel/m²
Whole display flatness: ≤ 1mm juncture
Best view distance: ≥ 9m
Viewing angle: Horizontal: 120° Vertical: 60°
Humidity(RH): ≤ 90~95%
Working temperature: from -30°C to +60°C
Working voltage: AC220V/110V±10%
Refresh frequency: 2400Hz(Zdec) ≥ 300Hz(Linsn)
Frame rate: ≥ 60Hz
Protection grade: IP54
MTBF: More than 10000hrs
Life time: 100,000 hrs
Control system Control system: BSTAR
Signal interface: AV.USB.DP.SDI
Communication distance: Internet cable: ≤120m / Fiber cable: 1000m
Systems operating platforms : XP,WINDOWS(WIN7,WIN10)

Payment term:


30% deposit, balance 70% before shipment


-T/T


-Western Union

Lead time:


-LED module: 5 to 7 working days upon receiving deposit payment.


-LED whole screen: 25 to 30 working days upon receiving deposit payment.

Packing:


-Anti-shaking wooden case, most economic package for outdoor full color LED

screen metal cabinet.


-Flight case, most easy transit, based on customer's requirements.

Shipping:


-EMS/DHL/FEDEX/UPS/TNT...any express are available for small parcel.


-Sea transportation to any sea port, or train transportation to Middle East Russia

line, or as customized.
