Specifications
Brand Name :
AMILA
Model Number :
Vacuum logical valve P2V
Place of Origin :
CHINA
MOQ :
Negotiatable
Price :
Negotiatable
Payment Terms :
L/C, T/T
Supply Ability :
Depending on the order quantity
Delivery Time :
Negotiatable
Packaging Details :
Carton package/Wooden cases
Fixed throttle aperture (mm) :
0.3-1.0mm
Characteristics :
One-Way Valve
Material :
Aluminium
Maximum service pressure range :
0-0.7 (MPa)
Maximum service vacuum pressure range :
-100-0 (Kpa)
The temperature of conditions and fluid precision :
5-60 (℃)
Description

Vacuum Logical Valve P2V Combined With Vacuum Suction Cup For Handling Workpieces

1. Operation principle in application

Vacuum Logical Valve P2V Combined With Vacuum Suction Cup For handling Workpieces

  • When a vacuum generator is provided with a plurality of suction cups, and the suction cups do not absorb the workpiece, the vacuum degree can be limited to drop.
  • When the vacuum suction cups does not catch the workpiece, the valve core will be closed by the air flow , and the flow can only pass through the fixed throttle aperture. At this time, each fixed throttle aperture can suck the corresponding air; When the vacuum suction cup catch the workpiece, the suction flow decreases, the valve core will be opened by the spring force , and the suction flow between the valve core and the housing will open.

2. Size

Vacuum Logical Valve P2V Combined With Vacuum Suction Cup For handling Workpieces

Vacuum Logical Valve P2V Combined With Vacuum Suction Cup For handling Workpieces

Vacuum Logical Valve P2V Combined With Vacuum Suction Cup For handling Workpieces
