Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA
Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA
Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA
Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA
Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA
Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA
Specifications
Brand Name :
Fiberplan
Model Number :
GYTA
Certification :
ISO 9001; TÜV certificate
Place of Origin :
China
MOQ :
1Km
Price :
Negotiation
Payment Terms :
L/C, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 km per month
Delivery Time :
5~8 work days
Packaging Details :
Wooden Drum
Application :
Telecommunication,Network
Fiber type :
G652B, G652D, G657A1, G657A2, 62.5/125, 50/125
Color :
Black,Customized
Jacket material :
PE,LSZH,PVC,TPU,LSZH OR PVC
Oem :
Available
Installation :
Burial/aerial/duct
Structure :
Loose tube
Operating temperature :
-40~75
Length :
Standard length of cable shall be 2 km. Other cable length is also availabler
Armored Material :
Aluminum armored
Bending Radius :
(long/short term): 10D/20D (mm)
Water Blcoking System :
Filling compound
Description

Outdoor Aluminum Tape Duct Armoured Fiber Optic Cable GYTA

Description

The cable secures fibers within a sturdy, water-resistant loose tube made of high modulus plastic, filled with

protective compound. A central steel wire provides strength, surrounded by tubes and fillers in a tight circular

core. Aluminum tape reinforces this core against water ingress, encased in a PE sheath for overall protection.

Application

1 Outdoor Distribution Adaptation: Tailored for outdoor environments, this cable is designed to thrive in outdoor

settings, ensuring reliable performance in varying weather conditions.

2 Versatile Installation: Its suitability for aerial installations or pipeline laying methods offers flexibility in deploy-

ment strategies, catering to different installation requirements.

3 Communication Flexibility: Whether for long-distance communication or local area networks, this cable facilit-

ates efficient data transmission across varying distances, making it adaptable for diverse communication setups.

Characteristic

* Outdoor-Ready Design: Tailored for outdoor use, this cable is built to withstand diverse environmental

conditions, ensuring reliable performance in outdoor settings.

* Versatile Installation Options: Its compatibility with aerial installation and pipeline laying methods prov-

ides flexibility in deployment, catering to various installation needs.

* Communication Versatility: Whether for long-distance transmissions or local area networks, this cable

enables efficient data transfer across different distances, making it suitable for a wide range of commun-

ication applications.

Cable construction details

Number of fiber 2~144core
Moisture Barrier Water blocking system
Central strength member Material Steel wire/FRP/FRP with PE cover
size 1.5mm~2.0mm
Loose tube material PBT
diameter Ф2.2(outer/inner)
Tube-filling Tube filling compoun
Armoring Material Aluminum/Steel tape
Outer sheath material PE,HDPE
diameter 8.0±0.2mm

Fiber color

Number of fiber

12 cores per tube

 1 2 3 4 5 6
Blue Orange Green Brown Grey White
7 8 9 10 11 12
Red Black Yellow Violet Pink Aqua
Color 13~24 will be marked with a black tracer.For black color no need marked black tracer, will use nature color instead.

Cable Mechanical characteristic

core Cable diameter weight
2 cores to 36 cores 10.0±0.4mm 90±3kg/km
39 cores to 72 cores 10.2±0.4mm 95±3kg/km
74 cores to 96 cores 12±0.4mm 135±3kg/km
98 cores to 120 cores 14±0.4mm 145±3kg/km
122 cores to 144 cores 16±0.4mm 204±3kg/km
Min Bending Radius(mm) Long term 10D
Min Bending
Radius(mm)		 Short term 20D
Min allowable
Tensile Strength(N)		 Long term 600
Min allowable
Tensile Strength(N)		 Short term 1500
Crush Load (N/100mm) Long term 300
Crush Load (N/100mm) short term 1000
Operation
temperature (℃)		 -40 ~ +75
Installation
temperature(℃)		 -15 ~ +60

Fiber characteristic

Fiber style Unit SM
G652		 SM
G652D		 MM
50/125		 MM
62.5/125		 MM
OM3-300
condition nm 1310/1550 1310/1550 850/1300 850/1300 850/1300
attenuation dB/km ≤ ≤ ≤ ≤3.0/1.0 ≤3.0/1.0
0.36/0.23 0.34/0.22 3.0/1.0 ---- ----
Dispresion 1550nm Ps/(nm*km) ---- ≤18 ---- ---- Dispresion
1625nm Ps/(nm*km) ---- ≤22 ---- ---- 　
Bandwith 850nm MHZ.KM ---- ---- ≧400 ≧160 Bandwith
1300nm MHZ.KM ---- ---- ≧800 ≧500 　
Zero dispersion wavelength nm 1300-1324 ≧1302,
≤1322		 ---- ---- ≧ 1295,
≤1320
Zero dispresion slope nm ≤0.092 ≤0.091 ---- ---- ----
PMD Maximum Individual Fibr 　 ≤0.2 ≤0.2 ---- ---- ≤0.11
PMD Design Link Value Ps(nm2*k
m)		 ≤0.12 ≤0.08 ---- ---- ----
Fibre cutoff wavelength λc nm ≧ 1180,
≤1330		 ≧1180,
≤1330		 ---- ---- ----
Cable sutoff
wavelength λcc		 nm ≤1260 ≤1260 ---- ---- ----
MFD 1310nm um 9.2±0.4 9.2±0.4 ---- ---- ----
1550nm um 10.4±0.8 10.4±0.8 ---- ---- ----
Numerical
Aperture(NA)		 　 ---- ---- 0.200±0.015 0.275±0.
015		 0.200±0
.015
Step(mean of bidirectional
measurement)		 dB ≤0.05 ≤0.05 ≤0.10 ≤0.10 ≤0.10
Irregularities over fiber
length and point		 dB ≤0.05 ≤0.05 ≤0.10 ≤0.10 ≤0.10
Dicontinuity
Difference backscatter
coefficient		 dB/km ≤0.05 ≤0.03 ≤0.08 ≤0.10 ≤0.08
Attenuation uniformity dB/km ≤0.01 ≤0.01 　 　 　
Core dimater um 　 　 50±1.0 62.5±2.5 50±1.0
Cladding diameter um 125.0±0.1 125.0±0.1 125.0±0.1 125.0±0.1 125.0±0.1
Cladding non-circularity % ≤1.0 ≤1.0 ≤1.0 ≤1.0 ≤1.0
Coating diameter um 242±7 242±7 242±7 242±7 242±7
Coating/chaffinch
concentrically error		 um ≤12.0 ≤12.0 ≤12.0 ≤12.0 ≤12.0
Coating non circularity % ≤6.0 ≤6.0 ≤6.0 ≤6.0 ≤6.0
Core/cladding conentricity error um ≤0.6 ≤0.6 ≤1.5 ≤1.5 ≤1.5
Curl(radius) um ≤4 ≤4 ---- ---- ----
