High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
Specifications
Place of Origin :
China, Shandong
Packaging Details :
standard packing
Supply Ability :
50 Set/Sets per Month
Price :
$25,000.00/sets >=1 sets
Brand Name :
DINGXING/DINGYI
Type :
Laminating Machine
Applicable Industries :
packing industry
Showroom Location :
Canada, Poland
Video outgoing-inspection :
Provided
Machinery Test Report :
Provided
Warranty of core components :
2 years
Core Components :
PLC, Engine, Motor, PLC, Engine, Bearing
Weight :
8000 KG
Warranty :
1 Year
Key Selling Points :
High-accuracy
Machine type :
Highspeed laminator
Electrical Control System :
Human Machine Interface with PLC control
Brand name :
HangSen
Speed :
12000pcs
After warranty service :
video technical support, online support, spare parts,
Voltage :
Customized
Automatic Grade :
Fully automatic
Precision :
±1mm
Marketing Type :
New product 2021
Port :
Qingdao
Description

High Speed Automatic Corrugated Carton Box Flute Laminating Machine Machinery High Speed Flute Laminator Line

High Speed Corrugated Carton Box Flute Laminating Machine Automatic
DX-1450
DX-1650
DX-1650XL
DX-2100
MAX
145*145
165*145
165*165
210*210
MIN
400*450
400*450
400*450
550*450
TOP GSM
120-600
120-600
120-600
120-600
BOT THICK
0.5-10MM A-N 2/3/5 corrugated board, grey paper board, cardboard
SPEED
150M/MIN
ACCURACY
±1.5MM
POWER
26KW
28KW
28KW
29KW
WEIGHT
7
7.5
7.5
8.5
Dimension
14056*2314*2560
14056*2514*2560
16598*2514*2560
17607*2964*2180
Computerized high-speed lamination at max.speed of 12,000 sheets per hour(Paper length:600mm) • Feeder Base: Low E-type piling table ensures direct paper feeding by pallet cart. Railway truck pre-loader is optional. • Gluing System:High-precision gluing rollers, glue side stopper, auto glue level
controller, no overflow at high speed and glue recirculation system. • Compensation Aligning System: multiple sensors detect relative position of bottom paper,while servo motors ensure dependent upper paper delivery compensation to guarantee precise aligning of two sheets. • Electrical Control System: Human Machine Interface with PLC control, warning light indicator, automatic detection of production condition, irregularities and job record. CE certified.
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine AutomaticHigh Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
High Speed Corrugated Carton Box Flute Laminating Machine Automatic
