High Precision ±1mm Laser Ranging Sensor with 40m Measuring Range and RS232 Output
High Precision ±1mm Laser Ranging Sensor with 40m Measuring Range and RS232 Output
High Precision ±1mm Laser Ranging Sensor with 40m Measuring Range and RS232 Output
High Precision ±1mm Laser Ranging Sensor with 40m Measuring Range and RS232 Output
High Precision ±1mm Laser Ranging Sensor with 40m Measuring Range and RS232 Output
High Precision ±1mm Laser Ranging Sensor with 40m Measuring Range and RS232 Output
Specifications
Brand Name :
KACISE
Model Number :
KLS220
Certification :
CE
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Measuring Range :
0.03~40m
Measuring Accuracy :
±1mm
Laser Grade :
Class 2
Working Voltage :
5~32V
Measuring Time :
0.4~4s
Frequency :
3Hz
Description
Industrial Laser Ranging Sensor RS232 Output
Introduction

KLS220 digital laser distance sensor is a high-precision distance measuring sensor with protection developed by our company. It has the characteristics of high measurement accuracy, fast measurement speed, and simple installation and operation. It has been widely used in various fields such as robotic arm protection measurement, industrial control and so on. The high range proximity sensor indoor 40m ranging range, ranging frequency is 3Hz, accuracy is 1mm, IP54 protection level, can be used in low temperature minus 10 ℃, needs to be customized. The light source of the distance ranging sensor is 635nm red light, class II laser grade, and can be used in material level and precise laser measuring and other occasions.

Product Features
  1. Small size, light weight and high precision
  2. The principle of phase method, suitable for indoor and outdoor models
  3. Industrial grade, mm error
Technical Parameters
ModelKLS220
Measuring Range0.03~40m
Measuring Accuracy±1mm
Laser GradeClass 2
Laser Type620~690nm,<1mW
Working Voltage5~32V
Measuring Time0.4~4s
Frequency3Hz
Size69*40*16mm
Weight40g
Communication ModeSerial Communication, UART
InterfaceRS232(TTL/USB/RS485/ Bluetooth can be customized)
Working Temperature0~40℃(Wide temperature -10 ℃ ~ 50 ℃ can be customized)
Storage Temperature-25℃-~60℃
