Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m
Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m
Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m
Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m
Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m
Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m
Specifications
Brand Name :
KACISE
Model Number :
LSEM
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Certification :
CE
Resolution ratio :
0.1m
Output :
UART
Measuring range :
3... 1000m
Aabsolute accuracy :
±1m
Service voltage :
Voltage range is DC3...3.5V
Power dissipation :
330mW
Description

Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m

1.Overview

The LSEM Outdoor Long - Distance Laser Radar Ranging Module by [Brand Name] is a remarkable device. It uses pulse method technology for long - range outdoor applications. With a compact 63×40×18mm size and weighing just 13g, it's easy to install. It offers high accuracy, achieving ±3mm absolute and 2mm duplicate accuracy, and has a measuring rate from 3 - 20Hz. The 635nm red visible laser with safety level 2 has a lifespan over 10,000 h. Operating in - 20~60℃ on DC2.5 - 3.3 V with low power, it's perfect for outdoor scenarios like construction and security.

Outdoor Long Distance Laser Radar Ranging Module with Aabsolute Accuracy ±1m

2.Product Features

  • Advanced Technology
  • Pulse - based Technology
  • Compact and Lightweight
  • High - Performance Ranging
  • Long - lasting Laser
  • Safe Light Source

3.Wide Operating Conditions

Measurement 0.03... 90% reflectivity in the 100m room
Duplicate accuracy 2mm
Absolute accuracy ±3mm
Measuring rate 3...20Hz
Measure the target object natural target
Laser life Over 10,000 h
light source 635nm red visible laser
Laser safety level 2
Typical light spot size 10m: 5x3mm; 25m: 10x6mm; 50m: 15x10mm 100m: 30x20mm
Interface UART
Working voltage DC2.5…3.3 V
Working temperature -20~60℃
power dissipation ＜0.27W
size 63×40×18mm
weight 13g
