KWS700B Industrial - Grade PH Detector
KWS700B Industrial - Grade PH Detector
KWS700B Industrial - Grade PH Detector
KWS700B Industrial - Grade PH Detector
KWS700B Industrial - Grade PH Detector
KWS700B Industrial - Grade PH Detector
Specifications
Brand Name :
KACISE
Model Number :
KWS700B
Place of Origin :
CHINA
MOQ :
1PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Certification :
CE
Temperature Range :
0 ~ 50℃
Work Pressure :
＜3 bar
Temp. Compensation :
Automatic temp. compensation
Output :
RS485, MODBUS protocol
Measuring Range :
0～14pH
Accuracy :
±0.02pH
Description

KWS700B Industrial - Grade pH Detector

1.Introduction

KACISE KWS700B Industrial - Grade pH Detector is engineered to meet the tough demands of industrial applications. It features a rugged construction with POM + Titanium wetted part material, capable of withstanding harsh industrial environments. Operating in a 0 - 50℃ temperature range and a work pressure of less than 3 bar, it remains stable. The digital sensor, with RS485 output and MODBUS protocol, can measure pH from 0 - 14 with ±0.02pH accuracy. Its long - life electrodes and automatic temperature compensation make it a reliable choice for industrial control and wastewater treatment processes.

2.Feature

  • Digital sensor, RS-485 output, standard MODBUS protocol;
  • No electrolyte required, strong anti-interference, no need for frequent calibration;
  • Built-in temperature sensor, automatic temperature compensation;
  • Adopt high-performance industrial online electrode, can work stably for a long time;
  • Built-in calibration parameters, accurately calibrated at factory, can be directly installed and used.

3.Technical Specifications

Model KWS-700B
Measuring Range 0～14pH
Accuracy ±0.02pH
Resolution 0.01
Temperature Range 0 ~ 50℃
Work Pressure ＜3 bar
Temp. Compensation Automatic temp. compensation
Output RS485, MODBUS protocol
Assembly

Connect with multi-parameter host

(can be used separately when connect cable)
Power Consumption 0.3W (suggest 12～24VDC, ≥1A)
Wetted Part Material POM+Titanium
Installation Immersion mounting
Cable Length 10 m, customizable
Calibration Method Two/three point calibration
IP Grade IP68
