Specifications
Brand Name :
Dwyer
Model Number :
2700 and 2800
MOQ :
1PCS
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Certification :
ce
Input Signal :
4-20 MA.
AccuracySeries 2800 :
±0.1% Of Span.
Electrical Connection :
1/2" Female NPT.
Pressure Connections :
1/4" Female NPT.
LinearitySeries 2700 :
<±0.5% Of Span.
Weight :
Series 2700: 1.3 Lb (0.59 Kg); Series 2800: 0.8 Lb (0.37 Kg).
Description

Series 2700 & 2800 Current to Pressure Transducer



Product Introduction



The Series 2700 and 2800 Current to Pressure Transducers are precision devices designed to convert variable current signals (4-20 mA) into proportional pneumatic outputs, ideal for controlling valve actuators, pneumatic positioners, and other industrial pneumatic equipment. Both series feature rugged NEMA 4X (IP65) enclosures for indoor/outdoor use and hold FM/CSA approvals for intrinsically safe operation. While the 2700 focuses on cost-effectiveness and high flow capacity, the 2800 incorporates advanced closed-loop feedback for enhanced stability in demanding environments.

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X

2700 2800 Current to Pressure Transducer 4-20 mA Input NEMA 4X


Features



Economical Performance: Combines low startup cost, minimal air consumption (0.03 scfm at midrange), and reliable operation, making it a cost-effective choice for standard applications.

Versatile Plumbing: Input and output ports on both front and back enable flexible installation (remote or panel mounting).

High Flow Capacity: Integral volume booster delivers up to 12.0 scfm (at 100 psig supply), accelerating control speed in critical systems.

Easy Calibration: External zero and span adjustments simplify field calibration.

Intrinsically Safe: FM/CSA approved for Class I, II, III hazardous locations, ensuring safe use in explosive environments.



Technical Specs at a Glance

Parameter Series 2700 Series 2800
Input Signal 4-20 mA 4-20 mA
Air Supply 5-100 psig (0.3-6.9 bar) 5-100 psig (0.3-6.9 bar)
Output Ranges 3-15 psig (0.2-1.0 bar); 6-30 psig (0.4-2.1 bar) 3-15 psig (0.2-1.0 bar); 6-30 psig (0.4-2.1 bar)
Enclosure NEMA 4X (IP65), chromate-treated aluminum NEMA 4X (IP65), chromate-treated aluminum
Connections 1/4" female NPT (pressure); 1/2" female NPT (electrical) 1/4" female NPT (pressure); 1/2" female NPT (electrical)
Agency Approvals CE, FM, CSA (intrinsically safe) CE, FM, CSA (intrinsically safe)
