Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Dwyer 607-9 Differential Pressure Transmitter 0-25 w.c. ±0.5% Accuracy
Specifications
Brand Name :
Dwyer
Model Number :
607-9
MOQ :
1PCS
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Service :
Dwyer 607-9 Differential Pressure Transmitter 0-25" W.c. ±0.5% Accuracy
Certification :
ce
Response Time :
250 Ms Max.
Accuracy :
±0.5% Or ±0.25% FS.
Product Type :
Differential Pressure Transmitter
Output Signal :
4 To 20 MA DC, 2-wire.
Temperature Limits :
-20 To 160°F
Description
Dwyer 607-9 Differential Pressure Transmitter 0-25" w.c. ±0.5% Accuracy
Product Attributes
Attribute Value
Product Type Differential Pressure Transmitter
Service Dwyer 607-9 Differential Pressure Transmitter 0-25" W.c. ±0.5% Accuracy
Accuracy ±0.5% Or ±0.25% FS.
Temperature Limits -20 To 160°F
Output Signal 4 To 20 MA DC, 2-wire.
Response Time 250 Ms Max.
Product Description

The Dwyer 607-9 is part of the Series 607 Differential Pressure Transmitters, designed for measuring differential pressure in air and compatible gases. It offers a measurement range of 0-25" w.c. with an accuracy of ±0.5%, making it suitable for demanding applications that require precise and reliable measurements.

As a 2-wire device with a 4-to-20 mA output, it integrates easily into industrial control systems. The Series 607 transmitters are known for combining very low ranges with exceptional stability and reliability, and each unit comes with certification to NIST standards, ensuring measurement accuracy and traceability.

Dwyer 607-9 Differential Pressure Transmitter 0-25 Dwyer 607-9 Differential Pressure Transmitter 0-25 Dwyer 607-9 Differential Pressure Transmitter 0-25 Dwyer 607-9 Differential Pressure Transmitter 0-25
Product Features
  • Precise Measurement: The 607-9 model provides a measurement range of 0-25" w.c. with ±0.5% accuracy, meeting the requirements of demanding applications.
  • Stability and Reliability: Features an ultra-thin glass clad silicon diaphragm design that resists shock and vibration, practically eliminating drift.
  • NIST Certification: Each unit includes certification to NIST standards, guaranteeing the accuracy and traceability of measurements.
  • Durable Housing: Housed in a tough stainless steel casing with a NEMA 2 rating, protecting against moisture and dirt.
  • Medium Compatibility: Specifically designed for use with air and other compatible gases.
  • Easy Integration: Adopts a 2-wire design with a 4-to-20 mA output, facilitating seamless integration into existing control systems.
Product Parameters
Model:
607-9
Type:
Differential Pressure Transmitter
Measurement Range:
0-25" w.c. (Series 607 ranges from 0-0.1" to 0-25" w.c.)
Accuracy:
±0.5% (Series 607 offers ±0.25% or ±0.5% accuracy)
Output:
4-to-20 mA
Wiring:
2-Wire
Compatible Media:
Air and compatible gases
Diaphragm Design:
Ultra thin glass clad silicon diaphragm
Certification:
NIST standards
Housing Material:
Stainless steel
Protection Rating:
NEMA 2
