Wika A-10 Pressure Transmitter

Product Introduction

The Wika A-10 pressure transmitter, a field-proven device, stands as the all-rounder for pressure measurement in industrial environments. With a compact build, it can be seamlessly integrated into a wide range of machine designs, making it highly versatile. Boasting numerous standard and special measuring ranges, it caters to universal applicability across various industrial scenarios.​

Backed by over ten years of proven performance in countless applications, the A-10 is a testament to Wika's extensive experience and deep understanding of customer needs. Its consistently high quality and reliable function are globally recognized and regularly confirmed by both internal and external audits, solidifying its position as a trusted bestseller in the industry.​

Product Features​

Exceptional Durability and Precision: Can tolerate up to 100 million load cycles with almost constant precision, ensuring long-term reliable performance even under frequent pressure fluctuations.​

Universal Applicability: Offers a large variety of measuring ranges, including special ones, covering almost all industrial pressure measurement needs. Its compact design allows integration into diverse machine designs.​

Proven Quality and Technology: Developed with years of experience and customer insights, it has been trusted in industrial applications for over a decade, with quality confirmed by regular audits.​

Flexible Accuracy Options: Available with optional improved non-linearity, with non-linearity values of ≤ ±0.5% of span or ≤ ±0.25% of span, catering to different precision requirements.​

Wide Application Range: Suitable for machine building, measurement and control technology, hydraulics and pneumatics, pumps and compressors, shipbuilding, and other general industrial applications.​

Compatible with Various Media: Designed to measure gases and liquids, enhancing its versatility in different industrial environments.​

Product Parameters​

Model: A-10​

Type: Pressure Transmitter (Pressure Sensor)​

Accuracy:​

Non-linearity: ≤ ±0.5% of span or ≤ ±0.25% of span (depending on option)​

Max. measured error per IEC 61298-2: Ranges from ≤ ±1% to ≤ ±2.4% of span based on measuring range (e.g., ≤ ±1% for ≥ 0.6 bar with ±0.25% non-linearity option)​

Output: 4-20mA​

Power Supply: 8-32VDC / 5VDC​

Zero Point Error:​

4-20mA / DC 1-5V / DC 0.5-4.5V / 0.5-4.5V ratiometric: ≤ ±0.3% of span (for ±0.5% non-linearity) or ≤ ±0.2% of span (for ±0.25% non-linearity)​

DC 0-10V: ≤ ±0.5% of span or ≤ ±0.4% of span​

DC 0-5V: ≤ ±0.6% of span (not possible with ≤ 0.1 bar ranges or ±0.25% non-linearity)​

Measuring Medium: Gases and Liquids​

Load Cycles Tolerance: Up to 100 million​

Application Fields: Machine building, measurement and control technology, hydraulics and pneumatics, pumps and compressors, shipbuilding, etc.​

Data Sheet Reference: Wika data sheet PE 81.60 ∙ 05/2023​
