Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Fluke PTi120 Compact Pocket Thermal Camera
Specifications
Brand Name :
FLUKE
Model Number :
PTi120
MOQ :
1PCS
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Certification :
CE
Brand :
Fluke
Single Package Size :
15X15X15 Cm
Single Gross Weight :
1.000 Kg
Color :
Yellow
Warranty :
1 Year
Description
Fluke PTi120 Compact Pocket Thermal Camera
Product Introduction
The Fluke PTi120 Compact Pocket Thermal Camera is a portable solution tailored for industrial inspection. It empowers users to conduct efficient infrared inspections, serving as the first line of defense for troubleshooting. Small enough for daily carry, it withstands harsh conditions like dirt, water, and drops, ensuring it's always ready for use. Ideal for quickly scanning temperatures of electrical equipment, machinery, and other assets, it helps prevent issues before they escalate, minimizing downtime. With features like IR - Fusion™ for easier problem - locating and Fluke Connect Asset Tagging for seamless image organization, it streamlines inspection workflows, making it a must - have tool for professionals on the job.

Fluke PTi120 Compact Pocket Thermal Camera

Fluke PTi120 Compact Pocket Thermal Camera

Fluke PTi120 Compact Pocket Thermal Camera

Key Features
Portability & Durability: Ultra - compact size for easy daily carrying. Boasts an IP54 enclosure rating, can survive a 1 - meter drop, and resists dirt and water, ensuring reliability in tough work environments.
Efficient Image Management: Fluke Connect Asset Tagging simplifies image sorting. Scan asset QR/barcodes to auto - store thermal images with timestamped info in predefined folders. Supports WiFi transfer and USB upload for efficient saving, finding, and reporting.
Advanced Imaging: 3.5” LCD touchscreen with IR - Fusion™ blends visible and infrared images. Adjust blending via finger sliding for easier problem location. Offers 6 standard color palettes (Ironbow, Blue - Red, etc.) for clear visual analysis.
Thermal Performance: Infrared resolution of 120 x 90 (10,800 pixels), IFOV 7.6 mRad, 50° H x 38° V field of view, and 130:1 distance - to - spot ratio. Thermal sensitivity (NETD) of 60 mK, 9 Hz frame rate, and fixed focus (min 22.8 cm focus distance).
Temperature Measurement: Two models cover - 20 °C to + 400 °C and - 20 °C to + 150 °C (not calibrated below - 10 °C). Accuracy of ± 2 °C or ± 2% for target temp ≥ 0 °C. Features on - screen emissivity correction and reflected background temp compensation.
Battery & Power: Internal rechargeable lithium - ion battery provides ≥ 2 hours of continuous use (without WiFi). Charges in ≤ 1.5 hours via Mini USB (to PC or with optional AC adapter). Offers automatic shutdown options (5 - 20 mins or never) for power saving.
Software & Compatibility: Works with Fluke Connect desktop software for full analysis and reporting. Supports non - radiometric (JPEG) and radiometric (.is2) image formats. JPEG files need no analysis software. Compatible with multiple languages.
Safety & Compliance: Meets safety standards like EN 61010 - 1 (CAT none, pollution degree 2), EN 60825 - 1 (Class 2), etc. Complies with electromagnetic compatibility and vibration/shock standards (2G, 25G).

Key Features
IFOV (spatial resolution) 7.6 mRad
Infrared resolution 120 x 90 (10,800 pixels)
Field of view 50° H x 38° V
Distance to spot 130:01:00
Temperature measurement range (not calibrated below -10 °C) -20 °C to +400 °C and -20 °C to +150 °C models
Focus system Fixed focus, minimum focus distance 22.8 cm
USB Mini USB used to transfer image to PC
Wifi Yes
Image quality
IR-Fusion technology Yes, adds the context of the visible details to your infrared image
AutoBlend mode Continuous 0% to 100%
Touchscreen display 3.5’’ (landscape), 320 x 240 LCD
Rugged, ergonomic design Yes
Thermal sensitivity (NETD) 60 mK
Frame rate 9 Hz
Data storage and image capture
Memory ≥ 2GB internal flash memory
Image capture, review, save mechanism One-handed image capture, review, and save capability
Image file formats Non-radiometric (jpeg), or fully radiometric (.is2); no analysis software required for non-radiometric (jpeg) files
Software Fluke Connect® desktop software—full analysis and reporting software with access to the Fluke Connect system
Export file formats with software JPG, IS2
Measurement range -20 °C to +400 °C and -20 °C to +150 °C models
Battery
Batteries (rechargable) Internal rechargeable lithium ion battery
Battery life ≥ 2 hours continuous (without WiFi)
Battery charging time ≤ 1.5 hours
Battery charging system Mini USB cord from product to PC
AC operation With separate AC to USB adapter. Not included in box.
Power saving Automatic Shutdown:
5, 10, 15 and 20 minutes or never
Temperature measurement
Temperature measurement range (not calibrated below -10 °C) -20 °C to +400 °C and -20 °C to +150 °C models
Accuracy Target temp at or over 0 °C: Accuracy: ± 2 °C or ± 2%
On-screen emissivity correction Yes
On-screen reflected background temperature compensation Yes
Color palettes
Standard palettes 6: Ironbow, Blue-Red, High Contrast, Amber, Hot Metal, Grayscale
General specifications
Infrared spectral band 8 μm to 14 μm (long wave)
Operating temperature -10 °C to +50 °C (14 °F to 122 °F)
Storage temperature -40 °C to +70 °C (-40 °F to 158 °F)
Relative humidity 95% non-condensing
Center-point temperature Yes
Spot temperature Hot and cold spot markers
Safety EN 61010-1: CAT none, pollution degree 2, EN 60825-1: Class 2, EN 60529, EN 62133 (lithium battery)
Electromagnetic compatibility EN301 489-1 V2.1.1 EN301489-17 V3.1.1
US FCC CFR, Part 15C
Vibration and shock 2G, IEC 68-2-6 and 25G, IEC 68-2-29
Drop 1 meter
Size (H x W x L) 8.9 cm x 12.7 cm x 2.5 cm
(3.5 in x 5.0 in x 1.0 in)
Weight (battery included) 0.233 kg (0.514 lb)
Enclosure rating IP54
Warranty Two-years
Supported languages Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
