Specifications
Brand Name :
Dwyer
Model Number :
SCG
MOQ :
1PCS
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
Certification :
CE
Place Of Origin :
Zhejiang, China
Warranty :
One Year
Customized Support :
OEM
Material :
Aluminum
Size :
113.98
Description
Series 2000 Magnehelic Differential Pressure Gages
The Series 2000 Magnehelic Differential Pressure Gages are versatile, mechanical instruments designed for precise low-pressure measurement in air and noncorrosive gas systems. With 81 models and 27 options, they indicate positive, negative (vacuum), or differential pressure without requiring power—making them ideal for isolation/hospital environments, temporary setups, and applications where electrical connectivity is limited.
Series 2000 Magnehelic Differential Pressure Gage with Mechanical Operation IP67 Weatherproof Rating and ±1% FS Accuracy
Product Features
  • Mechanical Operation: No power required for operation, suitable for off-grid or temporary installations. Direct mechanical indication of pressure via frictionless Magnehelic® movement.
  • Accuracy & Range: Standard accuracy: ±2% FS; -HA option achieves ±1% FS for critical measurements. Wide pressure range options (e.g., 0-0.1" w.c. to 0-250" w.c.) across 81 models.
  • Environmental Resistance: IP67 weatherproof rating; resists dust, water, shock, and vibration. Over-pressure tolerance: Suitable for pressures <35 psi (with Buna-N diaphragm for hydrogen applications).
  • Calibration & Certification: -HA models include mirrored scale overlay to reduce parallax error. NIST calibration and 6-point certification available via Product Configurator.
  • Versatile Applications: Hospital isolation wards, clean rooms, and temporary medical units. HVAC duct pressure monitoring, filter status indication, and building pressurization.
  • Cost-Effective Design: Low-cost alternative to electronic gauges without compromising reliability. Simple installation and maintenance-free operation.
Technical Specifications
Parameter Value
Accuracy Standard: ±2% FS; -HA: ±1% FS
Pressure Range Varies by model (e.g., 0-0.1" w.c. to 0-250" w.c.)
Power Requirement None (mechanical operation)
Environmental Rating IP67 (dust-tight and water-resistant)
Wetted Materials Aluminum, stainless steel, and Buna-N (optional for hydrogen)
Size 4.5" (114 mm) dial diameter
