GSRBA500D Quartz Flexible Accelerometer with ±70g Range, Small Size 22mm×22mm×14mm, and High Reliability for Aerospace and Applications
GSRBA500D Quartz Flexible Accelerometer with ±70g Range, Small Size 22mm×22mm×14mm, and High Reliability for Aerospace and Applications
Specifications
Brand Name :
Gyrosens
Model Number :
GSRBA500D
Certification :
CE
Place of Origin :
china
MOQ :
1pcs
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability :
1000 Piece/Pieces per Week negotiable
Delivery Time :
5-8 work days
Packaging Details :
each unit has individual box and all boxes are packed in standard packages or customers requests available
range :
±70g
Bias repeatability :
≤100ug
Bias temperature sensitivity :
100ug/°C
Bias stability :
≤100ug
Bias :
0g±2g
Size :
22mm×22mm×14mm
Description
GSRBA500D Quartz Flexible Accelerometer
Product Overview

The GSRBA500D quartz vibration beam accelerometer is a new solid-state digital output acceleration sensor featuring large range, compact size, high precision, low power consumption, rapid start-up time, shock vibration resistance, and exceptional reliability. This quartz vibration beam accelerometer offers significant advantages over traditional analog output accelerometers.

Key Features
  • Digital output
  • Wide bandwidth
  • Low power consumption
  • High reliability
  • Wide operating temperature range
  • Small size
  • Fast start-up
Applications
  • Spaceflight
  • Aviation
  • Navigation
  • Weapons
  • Vehicles
GSRBA500D Quartz Flexible Accelerometer with ±70g Range, Small Size 22mm×22mm×14mm, and High Reliability for Aerospace and Applications
Technical Specifications
Parameter GSRBA500D
Power Supply Parameters
Power Voltage 14~16VDC
Power @25°C 75mW @15VDC
Supply Current 5mA
Product Performance
Range ±70g
Size 22mm×22mm×14mm
Bias 0g±2g
Bias Stability ≤100μg
Bias Temperature Sensitivity 100μg/°C
Bias Repeatability ≤100μg
Scale Factor 56Hz/g±5Hz/g
Scale Factor Temperature Sensitivity 500ppm/°C
Second Order Nonlinear Coefficient ≤80μg/g²
Second Order Nonlinearity Coefficient Repeatability ≤50μg/g²
Scale Factor Repeatability ≤50ppm
Temperature Sensor 40KHz±2%(0.3Hz/°C)@25°C
Noise <10μg
Threshold ≤1×10⁻⁵g
Bandwidth ≥400Hz
Weight ≤23g
Environmental Specifications
Operating Temperature -45°C～+85°C
Storage Temperature -55°C～100°C
Random Vibration 5grms (20Hz～2000Hz)
Shock 200g
