Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Online Flexographic Label Printing Machine Film Plastic Printing Press
Specifications
Brand Name :
ruiting
Model Number :
RTRY-650-3
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
20 sets/month
Delivery Time :
in 30 days after receiving the deposit
Packaging Details :
Wooden Case
Type :
paper fexographic printing machine
Voltage :
380V,3phase,50HZ
Weight :
2500kg
Printing speed :
120m/min
Warranty :
1 Year
Product name :
3 color 650 flexo printing press
Printing material :
plastic adhesive label paper pvc pp pe
Plate thickness :
1.7mm/1.14mm(according your require)
Dimensions(l*w*h) :
3500mmX1800MMX 1200MM
Description

Product Description

Inline Flexo Printer Online Flexographic Label Printing Machine Film Plastic Printing Press

3 Color 650 Model inline flexo printing machine ,printing unit structure is consistent, the transmission is simple and reliable, the operation and maintenance are simple, the post-printing process is easy to connect, and the overprinting accuracy is high. It can realize the functions of die cutting, slitting and cold stamping in one machine.

Material details:

Printing material paper,foil, PVC, PET
Printing ink water based ink
Printing plate thcikness 1.7mm(according clinet require make)

Main features

1) 1 set ceramic anilox cylinder

2) 1 set plate cylinder

3) Magnetic powder brake controller for unwinding & rewinding

4) Tension controller for unwinding

5) Tension controller for rewinding

6) Printing unit: 360°Plate-adjustment

7) IR dryer each printing unit(UV dryer/LED UV option)

8)Feed paper form roll material, print, coating, dry automatically by infrared ray, laminating and rewinding completed in one time.

Main technical specification:

Model RTRY-650
Printing speed 120m/minute
Printing color number 3 color
Max width of paper 650mm
Max printing wide 650mm
Max unwinding diameter 1000mm
Max rewinding diameter 1000mm
Printing length 175-650mm
Precision of overprint ±0.1mm
Overall dimension 4.6(L)×1.8(W)×2.5(H)m
Weight about 3800kg

Optional parts:(can add as your request)

  • Printing unit number, up to 8 colors;
  • turn bar device;
  • Cold foil
  • Video monitor
  • Rotary die cutting set
  • Slitting set
  • Cold laminating


Online Flexographic Label Printing Machine Film Plastic Printing PressOnline Flexographic Label Printing Machine Film Plastic Printing PressOnline Flexographic Label Printing Machine Film Plastic Printing Press

Online Flexographic Label Printing Machine Film Plastic Printing PressOnline Flexographic Label Printing Machine Film Plastic Printing PressOnline Flexographic Label Printing Machine Film Plastic Printing Press

Online Flexographic Label Printing Machine Film Plastic Printing Press
