Specifications
Brand Name :
ruiting
Model Number :
RTZP-1680
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets per month
Delivery Time :
20 working days
Packaging Details :
wooden case
Weight :
3500KG
Dimension(l*w*h) :
6000*2100*1800mm
Warranty :
1 Year
Condition :
New
Packaging material :
Plastic/paper
Name :
Irregular Lamp Blister Blister Pack Packaging Sealing Machine
Function :
Packaging lamp,battery, lip
After-sales service provided :
Engineers available to service machinery overseas
Description

Product Description

Irregular Lamp Blister Blister Pack Packaging Sealing Machine

Heat sealing by the method of high frequency.The plastic and plastic(card,)or card and card sealed together when heated by the high frequency mold.The card always laminated by a PVC,APET or PETG sealing glue which will be melt by the high frequency.It took about 1 year to solve the difficulties in the connection of high frequency sealing machine and blister forming machine.So the electric parts(PLC,frequency transformer)never get interfered,all machines become synchronized and steady.

Application:

It is suit for daily use, stationery, minor hardware, cosmetics, medicines, as well as battery, toothbrush, pens, glues, plug base, bearing, etc. to improve the grade of the finished products.


Workflow:

↓

Pre-heat PVC

↓

Form blister

↓

Punch blister High frequency machine:

↓

Front blister into the sealing station→Automatic/Manual feeder→Load card→Back blister into sealing station→High frequency seal-Finished

Main Technical Specification:

Model RTZP-1680

Packing Material

 PVC/PET Roll Thickness(0.18-0.40) ×Width360mm
Cardboard (200-700)g

Air supply

 Pressure (0.55-0.8)Mpa
Air consumption 7.5m３/min

Power

 20Kw 380V 50Hz 3Phase 5Wire
High frequency machine power 15Kw

Mould cooling

 Tap water or Chiller Consumption 18L/h

Production capacity

 15Punches/Min.

Forming area

 340×220×50mm

Sealing area

 320×220×50mm

Stroke range

 (30-220)mm

Overall dimension(L×W×H )

 6000 x 2100 x1800 Mm

Weight

 Appr.3500Kg
