200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Specifications
Model Number :
UL30045
Brand Name :
MYSUN
Place of Origin :
Guangdong, China
MOQ :
1000
Conductor Material :
Copper
Diameter :
75mm2, 120mm2, 150mm2, 200mm2, 240mm2
Insulation Material :
Silicone Rubber
Rated Voltage :
600 V, 1500V, 1000V
Conductor Type :
Stranded
Temperature Rating :
200C, 150C
Insulation Type :
Insulated
Conductor Composition :
Tinned wire
Max Conductor Resistance :
199.0 Ω/KM (0.15mm2), 40.1 Ω/KM (0.50mm2), 24.8 Ω/KM (0.75mm2)
Unit Length :
610M/2000Ft (0.15mm2), 305M/1000Ft (0.50mm2-2.50mm2)
Conductor Construction :
7/0.18 (0.15mm2), 20/0.8 (0.50mm2), 30/0.18 (0.75mm2)
Insulation Thickness :
0.60mm (0.15mm2-2.00mm2), 1.00mm (2.50mm2)
Overall Diameter :
1.74mm (0.15mm2), 2.12mm (0.50mm2), 2.33mm (0.75mm2)
Color Options :
All colors
Conductor Size Range :
0.15mm2 to 150mm2
Description
High-Capacity Battery Cables: 75mm² to 400mm²
Premium silicone rubber insulated battery cables designed for high-performance applications in industrial and manufacturing sectors.
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China
Product Specifications
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
UL30045 Technical Data
Conductor Size (AWG/mm²) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm) Max. Cond Resistance (Ω/KM) Unit Length (M)/(Ft)
0.157/0.180.540.601.74199.0610/2000
0.5020/0.80.920.602.1240.1305/1000
0.7530/0.181.130.602.3324.8305/1000
1.0040/0.181.310.602.5118.7305/1000
1.5030/0.2541.600.602.8012.5305/1000
2.0040/0.2541.870.603.078.96305/1000
2.5050/0.2542.081.004.087.47305/1000
4.0128/0.202.91.004.904.70
6.0192/0.203.31.005.303.15
10.0379/0.204.61.908.401.80
16.084/0.44.51.908.3014
16.0510/0.206.01.909.801.15
12128/0.45.51.909.305.53
25.0797/0.207.52.2011.900.80
0.50mm²200/0.47.02.2011.4040.1
35.01115/0.208.82.2013.200.60
1.00mm²279/0.48.02.2012.4020
50.01593/0.2010.32.4015.100.40
2.00mm²399/0.410.32.4015.108.78
70.02230/0.2012.02.4016.800.30
357/0.512.02.4016.80
95.03026/0.2014.02.4018.800.20
485/0.514.02.4018.80
120.02368/0.25416.02.4020.800.17
612/0.516.02.4020.80
150.0765/0.517.52.4022.300.14
Customizable Packaging Available
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Company Profile
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire 200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Our Overseas Clients
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Exhibition
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Certifications
200C Rated Temperature 600V Rated Voltage Tinned Copper Conductor Battery Cable Silicone Rubber Wire
Frequently Asked Questions
Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
What Can We Provide?
We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
Why Choose Us?
A. Free Sample. B. Competitive Price. C. High Quality Standard. D. Customized Service.
What Certifications Do We Have?
We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
