200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
Specifications
Brand Name :
MYSUN
Place of Origin :
Guangdong, China
MOQ :
200
Conductor Material :
Copper
Diameter :
1 AWG, 2 AWG, 6 AWG, 4 AWG, 8 AWG, 10 AWG, 14 AWG, 12 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG
Insulation Material :
Silicone
Rated Voltage :
600 V
Conductor Type :
Stranded
Type :
Insulated
Rated Temperature :
-80C ~ +200C
Conductor :
Tinned wire
Insulation :
Silicone rubber
Max Conductor Resistance :
143 Ω/KM (26 AWG), 89.3 Ω/KM (24 AWG), 56.4 Ω/KM (22 AWG), 35.2 Ω/KM (20 AWG), 22.2 Ω/KM (18 AWG), 14 Ω/KM (16 AWG)
Unit Length :
305/1000 M/Ft (26 AWG)
Conductor Construction :
7/0.16 (26 AWG), 7/0.20 (24 AWG), 7/0.254 (22 AWG), 7/0.31 (20 AWG), 7/0.39 (18 AWG), 7/0.49 (16 AWG)
Nominal Thickness :
0.78 mm
Insulation Diameter :
2.04 mm (26 AWG), 2.17 mm (24 AWG), 2.33 mm (22 AWG), 2.5 mm (20 AWG), 2.75 mm (18 AWG), 3.05 mm (16 AWG)
Color :
All colors
Description
200 Degree UL Standard Super Soft Battery Cable
Supplies Fortune 500, Top Silicone Rubber Wire Supplier In China
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
UL3135 Technical Specifications
Conductor Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm) Max. Conductor Resistance (Ω/KM) Unit Length (M)/(Ft)
267/0.160.480.782.04143305/1000
247/0.200.610.782.1789.3
227/0.2540.770.782.3356.4
207/0.310.940.782.535.2
187/0.391.190.782.7522.2
167/0.491.490.783.0514
2411/0.160.610.782.1789.3
2217/0.160.760.782.3256.4
2026/0.160.940.782.535.2
1841/0.161.180.782.7422.2
1626/0.2541.490.783.0514
1441/0.2541.870.783.438.78
1219/0.472.630.783.925.53
0.30mm²12/0.180.710.782.2759.78
0.50mm²20/0.180.920.782.4840.1
0.75mm²30/0.181.130.782.6926.7
1.00mm²40/0.181.310.782.8720
1.25mm²50/0.181.460.783.0214.35
2.00mm²41/0.2541.870.783.438.78
2.50mm²50/0.2542.080.783.647.16
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications 200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications 200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications 200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications 200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications 200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
Company Profile
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications 200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
Our Overseas Clients
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
Exhibition
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
Certifications
200°C Rated Temperature UL Standard Super Soft Battery Cable Silicone Wire for Industrial Applications
Frequently Asked Questions
Who Are We?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
What Can We Provide?
We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
Why Choose Us?
A. Free Sample. B. Competitive Price. C. High Quality Standard. D. Customized Service.
What Certifications Do We Have?
We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
What Services Can We Provide?
Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
