UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
Specifications
Model Number :
UL3816
Brand Name :
Mysun
Place of Origin :
Guangdong, China
MOQ :
1000
Conductor Material :
Tinned Copper
Diameter :
4/0AWG, 3/0AWG, 2/0AWG, 50mm2, 75mm2, 90mm2, 120mm2, 1/AWG, 2AWG, 4AWG, 3AWG, 5AWG, 6AWG, 8AWG
Insulation Material :
XLPE
Rated Voltage :
3000V
Conductor Type :
Stranded
Shape :
Round
Temperature Rating :
150C
Max Temperature :
155℃
Nominal Thickness :
0.60mm, 0.78mm, 1.15mm, 1.53mm, 2.10mm
Max Conductor Resistance :
381Ω/KM, 239Ω/KM, 150Ω/KM, 94.2Ω/KM, 59.4Ω/KM, 36.7Ω/KM, 23.2Ω/KM, 14.6Ω/KM, 8.96Ω/KM, 5.64Ω/KM, 3.55Ω/KM, 2.813Ω/KM, 2.23Ω/KM, 1.768Ω/KM, 1.403Ω/KM, 0.882Ω/KM, 0.5548Ω/KM, 0.3487Ω/KM, 0.2766Ω/KM, 0.2194Ω/KM, 0.1722Ω/KM
Unit Length :
610/2000M
Conductor Construction :
7/0.10, 7/0.127, 7/0.16, 7/0.2, 17/0.16, 21/0.18, 16/0.254, 26/0.254, 41/0.254, 65/0.254, 105/0.254, 131/0.254, 166/0.254, 209/0.254, 263/0.254, 169/0.40, 268/0.40, 426/0.40, 537/0.40, 677/0.40, 547/0.40
Insulation Diameter :
1.50mm, 1.58mm, 1.70mm, 1.80mm, 2.32mm, 2.50mm, 2.75mm, 3.06mm, 3.45mm, 3.93mm, 4.58mm, 4.92mm, 6.05mm, 6.51mm, 7.85mm, 9.08mm, 10.66mm, 15.00mm, 16.40mm, 17.90mm, 19.60mm
MOQ :
1000M
Description
UL3916 XLPE Cable 3000V 150°C Tinned Copper High Voltage Wire
Supplies Fortune 500, Top New Energy Cable Supplier In China
Product Specifications
Size (AWG) Construction (No./mm) Diameter (mm) Nominal Thickness (mm) Diameter (mm) Max. Cond Resistance (Ω/KM) Unit Length (M/FT)
307/0.100.300.601.50381610/2000
287/0.1270.380.601.58239
267/0.160.500.601.70150
247/0.20.600.601.8094.2
2217/0.160.760.782.3259.4
2021/0.180.940.782.5036.7
1816/0.2541.190.782.7523.2
1626/0.2541.500.783.0614.6
1441/0.2541.890.783.458.96
1265/0.2542.370.783.935.64100/328
10105/0.2543.020.784.583.55
9131/0.2543.360.784.922.813
8166/0.2543.751.156.052.23
7209/0.2544.211.156.511.768
6263/0.2544.791.537.851.403
4169/0.406.021.539.080.882
2268/0.407.601.5310.660.5548
1/0426/0.4010.82.1015.000.3487
2/0537/0.4012.22.1016.400.2766
3/0677/0.4013.72.1017.900.2194
4/0547/0.4015.422.1019.600.1722
Contact us for a competitive quote
Our Products
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
Application
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
Company Profile
UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems UL3916 XLPE Cable 3000V 150C Tinned Copper High Voltage Wire for EV & High Voltage Systems
Frequently Asked Questions
How can I contact your company?
We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile
What is your working time?
Monday-Saturday: 7:30AM-17:00PM (Beijing time, GMT+08:00). We have public holiday during May 1-3, Oct 1-7 and Chinese New Year holiday. Please email us during our holiday if you have any questions.
Do you provide free samples?
Yes, we can provide a free sample for testing. Buyer should bear all the shipping costs.
What is your payment terms?
T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal
What is the lead time?
Usually sample lead time is 7 days after payment has been confirmed.
