Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Specifications
Model Number :
UL3122-0.3mm
Brand Name :
MYSUN
Place of Origin :
Guangdong, China
Certification :
ROHS/CCC/VDE/CCC/ISO9001:2008
MOQ :
3050
Price :
$0.08-0.16
Conductor Material :
Copper
Insulation Material :
Rubber
Rated Voltage :
300 V
Conductor Type :
Stranded
Shape :
Round
Temperature Rating :
200C
Conductor Composition :
Tinned Copper
Insulation Type :
Silicone Rubber
Package Length :
305 meter/roll
Max Conductor Resistance :
143.00 Ω/KM
Conductor Diameter :
0.48 mm
Insulation Thickness :
0.60 mm
Insulation Diameter :
1.68 mm
Unit Length :
305/1000 M/Ft
AWG Size :
26
Description
Products Description
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Specification
Conductor
Insulation
Max.Cond
Resistance
(Ω/KM)
Unit length
(M)(Ft)
Size
(AWG)
Construction
(No./mm)
Diameter
(mm)
Nominal Thickness
(mm)
Diameter
(mm)


26
7/0.16
0.48
0.60
1.68
143.00
305/1000
24
7/0.20
0.61
0.60
1.81
89.30
305/1000
22
7/0.254
0.77
0.60
1.97
56.40
305/1000
20
7/0.31
0.94
0.60
2.14
35.20
305/1000
18
7/0.39
1.19
0.60
2.39
22.20
305/1000
16
7/0.49
1.49
0.60
2.69
14.00
305/1000
24
1/0.50
0.5
0.65
1.80
89.30
305/1000
22
1/0.65
0.65
0.65
1.95
56.40
305/1000
20
1/0.81
0.81
0.65
2.11
35.20
305/1000
18
1/1.02
1.02
0.65
2.32
22.20
305/1000
16
1/1.20
1.2
0.65
2.50
14.00
305/1000
24
11/0.16
0.61
0.60
1.81
89.30
305/1000
22
1 7/0.16
0.76
0.60
1.96
56.40
305/1000
20
26/0.16
0.94
0.60
2.14
35.20
305/1000
18
41/0.16
1.18
0.60
2.38
22.20
305/1000
16
26/0.254
1.49
0.60
2.69
14.00
305/1000
0.30m㎡
12/0.18
0.71
0.60
1.91
59.78
305/1000
0.50m㎡
20/0.18
0.92
0.60
2.12
40.10
305/1000
0.75m㎡
30/0.18
1.13
0.60
2.33
26.70
305/1000
1.00m㎡
40/0.18
1.31
0.60
2.51
20.00
305/1000
1.25m㎡
50/0.18
1.46
0.60
2.66
14.35
305/1000
item
value
Place of Origin
China
Guangdong
MYSUN
UL3122
Type
insulated
Application
home appliance,lighting,heater,motor,generator,industrial power
Conductor Material
Copper
Conductor Type
Stranded
Insulation Material
Rubber
Color
Accept Customized
Conductor
Tinned Copper
Usage
High Temperature Electric Furnace Heating
Insulation
Silicone Rubber
Rated Voltage
300V
Rated Temperature
200 Degree
Package
305 meter/roll
Certification
ROHS/CCC/VDE/CCC/ISO9001:2008
Product name
Copper Core silicone rubber Insulation Wire
Material
Standard Copper
Company Profile
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Heat-Resistant UL3122 Silicone Insulated Copper Wire with 200C Rated Temperature and 300V Voltage for Home Appliances in 305 Meter Rolls
Shenzhen Mysun Insulation Materials Co., Ltd. is a comprehensive enterprise integrating the manufacture, distribution and trade. We specialize in producing all sorts of wires with high temperature, home appliances, electronic products, lightings, medical units, communication and office equipment with connecting wiring harness and processing service. Our wires have passed the evaluations of UL, CUL, VDE and SGS certifications. Our company has been managed according to international standard management system of ISO9001. We are looking forward to serving you with our management principle of "group, service, innovation and responsibility" and quality policy of "full participation, prevention first, persisting improvement and satisfying service". Please feel free to contact us for further information.
Packing
Application
FAQ
How can I contact with your company? We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile What is your working time? Monday-Saturday : 7:30AM-17:00PM (Beijing time, GMT+08.00) We have public holiday during May.1-3, Oct.1-7 and Chinese New Year holiday . Pls email us during our holiday if u have any question Do you provide free samples? Yes, we can provide a free sample for testing,buyer should bear all the shipping costs. What is your payment terms? T/T,L/C,D/A,D/P,Western Union,MoneyGram,Paypal What is the lead time? Usually sample lead time is 7 days after payment has been confirmed.
