UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
Specifications
Place of Origin :
Guangdong, China
Brand Name :
MYSUN
Model Number :
UL1330
MOQ :
6100
Temperature rating :
200℃
Shape :
ROUND
AWG sizes :
12, 20, 22, 24, 8, 14, 16, 18, 6, 2, 4
Conductor material :
Tinned Copper
Conductor type :
Solid
Insulation material :
FEP
Rated voltage :
600V
Unit length :
305/1000
Max resistance :
See table
Conductor diameter :
See table
Insulation thickness :
See table
Overall diameter :
See table
Standard :
UL758
Voltage rating :
600V
Conductor construction :
See table
Description
UL1330 FEP Wire High Temperature Tefzel Insulated Wire
Product Specifications
Attribute Value
Temperature Rating 200°C (392°F)
Shape Round
Available Diameters 2 AWG to 30 AWG (multiple sizes available)
Type Insulated Wire
Primary Application Medical Equipment
Conductor Material Tinned Copper
Conductor Type Solid
Insulation Material FEP (Fluorinated Ethylene Propylene)
Rated Voltage 600V
Standard UL758
Available Colors All standard colors
Standard Length 305m/1000ft
Technical Specifications
Size (AWG) Conductor Construction Conductor Diameter (mm) Insulation Thickness (mm) Overall Diameter (mm) Max Conductor Resistance (Ω/KM) Unit Length (M/Ft)
30 7/0.10 0.30 0.50 1.30 381 610/2000
28 7/0.12 0.38 0.50 1.38 239 610/2000
26 7/0.16 0.48 0.50 1.48 150 610/2000
24 19/0.12 0.60 0.50 1.60 94.2 610/2000
22 19/0.15 0.75 0.50 1.75 59.4 305/1000
20 19/0.19 0.93 0.50 1.93 36.7 305/1000
18 19/0.235 1.17 0.50 2.17 23.2 305/1000
16 19/0.30 1.50 0.50 2.50 14.6 305/1000
14 19/0.37 1.85 0.50 2.85 8.96 305/1000
12 19/0.47 2.35 0.50 3.35 5.64 305/1000
Key Features
  • High temperature resistance up to 200°C (392°F)
  • FEP (Tefzel) insulation for excellent chemical and abrasion resistance
  • Tinned copper conductor for superior conductivity and corrosion resistance
  • UL758 certified for quality assurance
  • Available in multiple AWG sizes from 2 to 30
  • 600V rated for various industrial applications
  • Ideal for medical equipment and other demanding environments
UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper UL1330 FEP Tefzel Insulated Wire 200C 600V Tinned Copper
Frequently Asked Questions
1. Who are we?
We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, with production bases in Dongguan and Jingzhou.
2. What can we provide?
We specialize in high-temperature wires and cables, including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
3. Why choose us?
• Free samples available
• Competitive pricing
• High quality standards
• Customized services
4. What certifications do we have?
Our products are certified to UL, cUL, VDE, Reach, CE, ROHS, CCC, and CQC standards.
5. What services can we provide?
We accept various delivery terms (FOB, CIF, EXW, etc.) and payment methods (T/T, L/C, PayPal, etc.) in multiple currencies (USD, EUR, CNY).
