Specifications
Brand Name :
Suzhou Desisen (DSS) Electronics
Model Number :
SWT-662
Certification :
ISO 9001, CE
Place of Origin :
China
MOQ :
1 set
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
100 sets
Delivery Time :
2-3 weeks
Packaging Details :
wooden case
working temperature :
-15~55℃
saving temperature :
-20~60℃
relative humidity :
not exceed 85%
working voltage :
AC220±10V
Description

Product Description:

SWT-662 full automatic eddy current flaw detector (double channels) ,it adopts full automatic electromechanical integration testing machine controlled by the latest eddy current technology ,microprocessor .the function is powerful, the operation is simple and intelligent ,high degree of automation . It adopts software written by WINDOWS operating platform make instrument operating easier and intelligent .the performance of instrument is stable and reliable , it is the ideal equipment of shot metal bar,metal accessory flaw detection ,hardness selection .

Features:

1. Applicable targets: shot metal bar flaw detector and hardness selection

2. Double channels (it is equal to working efficiency of two independent machine )

3. Testing frequency range:100Hz ~ 2MHz changeable

4. Specification and dimension:≧Ф0.5mm

5. It can test flaw deeper than 0.1MM,±1HRC hardness

6. Supplying, sorting ,counting automatically

7. The speed of testing is one piece per second(double channels)

8. Sample rate :4×25000 times/second

9. Gain amount :0－70dB changeable

10. Phase position :0－360°arbitrary adjustable

11. It adopts industry controlling computer ,WINDOWS operating platform flaw detection software

12. There is no damage after sorting


Technical Parameters:

Name Portable Eddy Current Flaw Detector SWT-662 type
The number of channels 2
Gain amount 80dB,stepping is 0.1dB
frequency multiple
The speed of flaw detection ≤350meter/minute
Frequency range 100 Hz ~ 2 MHz
Gain 0～70dB,stepping is 0.5dB
Phase rotation 0~360° stepping is 1 °
Ratio of gains(Y/X) 0.1~10
Gains /phase position test manual and automatic
Showing model spot line blanking
High -pass filtering high/middle/low
Digital filtering spots 1 ~ 100
Working model inside outside clock
Probe excitation signal amplitude 1-8V

Support and Services:

Technical Support and Service for SWT-662 type Automatic Flaw Detector

We provide technical support and service to ensure our customers are satisfied with their Portable Eddy Current Flaw Detector. We offer both on-site and online support for all of our products.

On-site Support

Our on-site support team is available to help with any installation, troubleshooting, or maintenance related issues you may have with your Portable Eddy Current Flaw Detector. Our technicians can come to your location and help with any questions or problems you may have.

Online Support

Our online support team is available 24/7 to help with any questions or issues you may have with your Portable Eddy Current Flaw Detector. We have a live chat feature on our website, as well as an online ticket system for more in-depth issues. Our team is always available to help.

FAQ:

Q1: What is the brand name of this product?

A1: The brand name of this product is Desisen.

Q2: What is the model number of this product?

A2: The model number of this product is SWT-662 type Automatic.

Q3: Where is this product made?

A3: This product is made in China.

Q4: Does this product have any certification?

A4: Yes, this product has ISO9001 certification.

Q5: What's the minimum order quantity?

A5: The minimum order quantity is 1.
