OP07CDR Audio Power Amplifier IC Precision Amplifiers Low Offset Volt Prec
OP07CDR Audio Power Amplifier IC Precision Amplifiers Low Offset Volt Prec
Specifications
Brand Name :
Ti
Model Number :
OP07CDR
MOQ :
Contact us
Price :
Contact us
Payment Terms :
Paypal, Western Union, TT
Supply Ability :
50000 Pieces per Day
Delivery Time :
The goods will be shipped within 3 days once received fund
Packaging Details :
SOP
Description :
General Purpose Amplifier 1 Circuit 8-SOIC
Ib - Input Bias Current :
7 nA
Vos - Input Offset Voltage :
0.25 mV
en - Input Voltage Noise Density :
10.5 nV/sqrt Hz
Supply Voltage - Max :
36 V
Supply Voltage - Min :
6 V
Operating Supply Current :
2.4 mA
Description

OP07CDR Audio Power Amplifier IC Precision Amplifiers Low Offset Volt Prec

1 Features

  • Low Noise

  • No External Components Required

  • Replace Chopper Amplifiers at a Lower Cost

  • Wide Input-Voltage Range: 0 to ±14 V (Typ)

  • Wide Supply-Voltage Range: ±3 V to ±18 V

2 Applications

  • Wireless Base Station Control Circuits

  • Optical Network Control Circuits

  • Instrumentation

  • Sensors and Controls

  • Precision Filters

3 Description

These devices offer low offset and long-term stability by means of a low-noise, chopperless, bipolar-input-transistor amplifier circuit. For most applications, external components are not required for offset nulling and frequency compensation. The true differential input, with a wide input-voltage range and outstanding common-mode rejection, provides maximum flexibility and performance in high-noise environments and in noninverting applications. Low bias currents and extremely high input impedances are maintained over the entire temperature range.

Device Information

PART NUMBER

PACKAGE (PIN)

BODY SIZE

OP07x

SO (8)

6.20 mm × 5.30 mm

SOIC (8)

4.90 mm × 3.91 mm

PDIP (8)

9.81 mm × 6.35 mm
