Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Specifications
Brand Name :
YUYANG
Model Number :
YY20
Certification :
CE,CO
Place of Origin :
China
MOQ :
1 set
Price :
$993-$1250
Capacity options :
100KG
Measurement accuracy :
± 1%
Resolution :
1/250000
Test speed :
0 ~ 300 mm/min
Effective travel :
600 mm
Test space :
1200 mm
Power units :
kgf, gf, N, kN, lbf
Stress unit :
MPa, kPa, kgf/cm2, lbf/in2
Stop mode :
upper and lower limit safety setting, specimen breakpoint sensing
Result output :
Micro printer
Dynamic force :
speed regulating motor
Optional :
Tension fixture (conventional)
Machine weight :
about 40 kg
Power supply :
1PH, AC220V, 50/60Hz
Description
ASTM PS79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
This manual tensile strength tester is specifically designed for evaluating the pull-out strength of snap buttons on children's garments and clothing, ensuring safety and durability compliance with ASTM PS79 standards.
Astm Ps79 Manual Kids Garment Clothes Snap Button Pull Out Tensile Strength Tester
Product Applications

Ideal for evaluating tensile strength, peeling strength, deformation rate, breaking force, peeling force, and opening force across a wide range of materials, including plastic film, composite film, adhesive, adhesive tape, medical patch, protective film, release paper, rubber, artificial leather, paper fiber, and more.

Testing Standards Compliance
GB16491-2008, HGT 3844-2008, QBT 11130-1991, GB 13022-1991, HGT 3849-2008, GB 6349-1986, GB/T 1040.2-2006 2411, ISO 4587, ISO/TS 11405, ISO 527, ASTM E4, BS 1610, DIN 52121, ISO 7500, EN 10002, ASTM D628, ASTM D638, ASTM D412
Intended Users
Ideal testing and research device for factories, technical supervision departments, inspection institutions, research institutes, and universities.
Primary Functions
Primarily used to test mechanical properties of metals (tension, compression, bending) and automatically calculates parameters such as tensile strength, yield strength, elongation, constant elongation stress, constant stress elongation, and modulus of elasticity according to standards like GB, JIS, ASTM, and DIN.
Key Features
  • Innovative material testing machine with fully computerized operation, evolved from conventional testing machines to eliminate bulkiness and complexity
  • Integrated panel and aluminum profile plate structure with high precision, low resistance, and seamless precision ball screws and guide columns for enhanced load efficiency and structural rigidity
  • Advanced servo motor drive system with servo driver for high transmission efficiency, stable operation, low noise, and accurate speed control
  • Computer-based control system with QCTech testing software for complete test parameter setting, status control, data collection & processing, result display, and printing
  • Dedicated testing system supporting tension, compression, bending, shearing, tearing, and peeling tests with comprehensive data processing capabilities
Technical Parameters & Specifications
Software Technical Parameters
Software operating system language: English. Force units (N, KN, Kgf, Lbf) and length units (mm, cm, in) can be freely converted.
Control Modes
Computer software configures control methods for speed, load fracture, running time, etc. Dedicated manual operation box facilitates calibration and positioning when loading and holding test specimens. Automatically detects material fracture, breakage, etc., and stops automatically; automatic return can be configured.
Curve Types
Load-displacement, Load-time, Displacement-time, Stress-strain, Strain-time, Stress-time. Horizontal and vertical coordinates of the curve can be set arbitrarily.
Available Test Data
Maximum strength, minimum strength, fracture value, upper/lower yield strength, tensile strength, compressive strength, modulus of elasticity, elongation, maximum value, minimum value, average value, etc. (Customers need to select these before ordering)
Safety Features
Multiple protections including overload, overcurrent, overvoltage, undervoltage, overspeed, stroke limit, etc. Data results follow the standard report format specified by the current standard.
