Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment
Specifications
Model Number :
YY F056
Power Supply :
0.5kVA, 220V, 50-60Hz
MOQ :
1 set
Delivery Time :
7-30 Days
Repeated Ignition Cycles :
1 ~ 9999 times (digital preset available)
Ignition & Removal Time :
1s ~ 999.9s (digital preset available)
Packaging Details :
Plywood Box
Payment Terms :
L/C, D/A, D/P, T/T, Western Union
Test Inclination Angle of Lamp :
0°, 45°, 90°, quick positioning; Max travel approx. 150mm
Flame Holding Time :
1s ~ 999.9s (digital display, non-preset)
Certification :
CE
Brand Name :
YUYANG
Place of Origin :
China
Price :
$1620-1700
Test Gas :
98% Methane (reference gas); or natural gas of 37MJ/m³ ±1MJ/m³
Supply Ability :
200 sets per month
Bunsen Lamp :
Tube diameter: 9.5mm ± 0.1mm
Description
Horizontal Vertical Burning Tester for Plastic and Rubber Testing

The Horizontal Vertical Burning Tester is a dedicated flammability testing instrument engineered for evaluating the burning behaviour of plastic and rubber materials. It supports both horizontal and vertical test orientations, allowing laboratories and quality control teams to assess ignition resistance, flame spread, and self-extinguishing characteristics under controlled conditions.

Horizontal Vertical Burning Tester Plastic Rubber Testing Equipment

Horizontal and vertical burning test configuration for plastic and rubber specimens

Key Testing Capabilities
  • Dual-mode testing with both horizontal and vertical specimen positioning
  • Designed for flammability evaluation of plastic and rubber materials
  • Supports assessment of flame spread rate and afterflame behaviour
  • Suitable for material research, incoming inspection, and quality control
  • Stable, repeatable test conditions for consistent comparative results
Typical Applications

This burning tester is widely used in plastics manufacturing, rubber processing, wire and cable production, automotive component testing, and third-party material testing laboratories. It helps manufacturers verify that raw materials and finished parts meet internal safety specifications and applicable flammability standards.

Product Specifications
Product Type Horizontal Vertical Burning Tester
Application Plastic and rubber flammability testing
Test Orientation Horizontal and vertical
Equipment Category Flammability testing equipment
