30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
Specifications
Brand Name :
YUYANG
Model Number :
YYD-30D
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
pending
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
200 sets per month
Delivery Time :
5-10 work days
Packaging Details :
Plywood Box
Max Load :
30kn
Load Accuracy :
Grade 1 or Grade 0.5
Test Range :
2-100%FS or 0.4-100%FS
Load Resolution :
1/500000FS
Test Control Mode :
3 closed loop control, stress, strain and displacement
Tensile/ Compression Space :
750mm
Test Width :
400mm
Deformation Accuracy :
≤±1%
Displacement Resolution :
0.01mm
Crosshead Speed Range :
0.001～500mm/min
Overall Dimensions (L*W*H) :
770*500*1830mm
Power :
0.75kw
Supply Voltage :
1P 220V±10%,50-60HZ,500W
N.W. :
300kg
Operating Temperature :
0 to +38°C (+32 to +100°F)
Humidity Range :
10% to 90% non-condensing
Description
30kN Dual Column Electromechanical Universal Testing Machine
Professional tensile, compression, and bending testing equipment with precise digital control system for accurate material testing applications.
30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending 30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending 30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending 30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending 30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending 30kN Dual Column Electromechanical Universal Testing Machine Tensile Compression Bending
Technical Specifications
Control Mode Digital Display System
Model YYS-5D YYS-10D YYS-20D YYS-30D YYS-50D YYS-100D
Max Load 5KN 10KN 20KN 30KN 50KN 100KN
Load Accuracy Grade 1
Test Range 2-100%FS
Tensile/Compression Space 800mm 789mm 750mm 650mm -
Test Width 300mm 315mm 400mm 410mm -
Deformation Accuracy ≤±1%
Displacement Resolution 0.01m
Crosshead Speed Range 0.001～500mm/min
Overall Dimensions (L*W*H) 420*300*1500mm 663*430*1700mm 770*500*1830mm 800*500*1950mm -
Power 0.3kw 0.75kw 1kw -
Operating Temperature 0 to +38°C (+32 to +100°F)
Humidity Range 10% to 90% non-condensing
NOTE:
1. Extra wide and/or extra height frames are available.
2. Power supply system is completely customizable.
Company Information & Services
About Our Company
Based in Guangdong, China, established in 2018. We serve global markets including South Asia (20%), Eastern Asia (20%), Domestic Market (15%), Southeast Asia (15%), Eastern Europe (10%), North America (10%), Oceania (5%), and Western Europe (5%). Our team consists of 11-50 professionals.
Quality Assurance
  • Pre-production samples provided before mass production
  • Final inspection conducted before shipment
Product Range
We specialize in: Fire Testing Equipment, Environmental Test Chambers, Textile Testing Equipment, Toys Testing Equipment, and Wire and Cable Test Machines.
Why Choose Us
As a high-tech enterprise, we specialize in developing and manufacturing comprehensive testing solutions including Fire Testing Equipment, Building Material Fire Testers, Wire and Cable Fire Testers, Environmental Test Chambers, Textile Testing Equipment, and Toys Testing Equipment.
Services Provided
  • Delivery Terms: FOB, CFR, CIF, EXW
  • Payment Currencies: USD, EUR, JPY, AUD, HKD, GBP, CNY
  • Payment Methods: T/T, L/C, D/P D/A, Credit Card, Western Union, Cash
  • Languages: English, Chinese
