High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
Specifications
Load ability :
20KG
Work Environment :
Temperature -10℃-40℃ ,relative humility 30-90%
Belt Width(mm) :
400
Brand Name :
YUYANG
Application :
Non-package ,plastic package ,paper bag or box (non-metallic) product
Model Number :
YY056
Reject Ways :
no auto-reject system ,belt continue and rejecting the goods
MOQ :
1PCS
Detected Height(mm) :
300
Warning method :
Sound and light alarm ; The belt can be stopped, continue run or belt return ( the option you can selected in PLC controller)
Payment Terms :
T/T
Detector sensitivity(mm) :
Fe 1.0mm SUS 2.0mm N-Fe 1.5mm
Count :
100
Price :
$2350-$2798
Speed of belt :
25M/min (Fixed speed) ; If you need adjust 5-40 M/min , please inform us before order
Delivery Time :
7-30 Days
Belt length :
1500
Certification :
CE
Place of Origin :
China
Description
High Sensitivity Industrial Food Metal Detector Conveyor System
High Precision Automatic Digital Metal Detector for Foreign Object Detection
High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection High Sensitivity Industrial Food Metal Detector Conveyor System for Foreign Object Detection
Product Specifications
Material Stainless steel
Machine Length 1600mm
Model Number YY056
Speed of Belt 25M/min (Fixed speed)
Speed of Transmission 18-40 meter/minute
Customized Support OEM, ODM, OBM
Type Laboratory equipment
Sample Plate Angle 0~70°
Dimension 72*53*56cm
Test Accuracy ±2％
Working Speed 0-18 rotate/min can be adjustable
Pressure Source Air pressure more than Min.5kg/cm²
Size Customized
Applications & Industries
The through-type fully digital metal detection machine is a new generation intelligent metal detector adopting microcomputer-based technology. Equipped with high detection sensitivity and reliable performance, it addresses the technical challenge whereby the majority of comparable devices are only sensitively responsive to magnetic substances.
Primary Use Cases
Main applications cover sauces, sausages, dumplings, ham, soup, sugar products, pickled and salted food, fast food and diverse non-food industries.
Achieves premium detection performance for high-moisture and frozen commodities. Capable of detecting both ferrous and non-ferrous metals including residual/broken needles, metal wires, lead, copper, aluminium, tin, stainless steel and other metallic contaminants inside food, raw materials and finished products.
Key Features
  • Dual-Circuit Electromagnetic Detection Technology - Combines advanced analog and digital circuits to improve detection sensitivity, accuracy, and reliability
  • Intelligent Touch Screen Control - Equipped with modern touch screen and large-scale integrated circuit system for smarter operation
  • User-Friendly Human-Machine Interface - Supports multi-language operation with clear and intuitive interface
  • Automatic Learning & Dynamic Zero Tracking - Features dynamic zero-point voltage tracking and automatic learning function
  • Wide Sensitivity Adjustment Range - Sensitivity can be adjusted according to different products and production requirements
  • Alarm and Optional Reject Function - Simultaneous sound and light alarm with conveyor stop, continue, or reject options
Technical Parameters
Detected Height (mm) Belt Width (mm) Belt Length Fe Sensitivity (mm) SUS Sensitivity (mm) N-Fe Sensitivity (mm)
80 250 1500 0.8 1.0 1.0
100 250 1.0 2.0 1.5
150 400 1.2 2.5 2.0
200 400 1.5 2.5 2.0
250 400 2.0 3.0 2.5
300 400 2.5 3.5 3.0
350 400 3.0 4.0 3.5
Additional Specifications
  • Speed of belt: 25M/min (Fixed speed); Adjustable 5-40 M/min available upon request
  • Load ability: 20KG
  • Count: 100
  • Warning method: Sound and light alarm with PLC controller options
  • Reject Ways: Auto-reject system with continuous belt operation
  • Application: Non-package, plastic package, paper bag or box (non-metallic) products
  • Work Environment: Temperature -10℃-40℃, relative humidity 30-90%
Advanced Technology Features
  • Balance theory implementation for enhanced reliability
  • Phase-adapted technology to effectively eliminate product effect
  • Self-learning function with automatic digital learning and storage of product features
  • Easy operation without manual adjustment of technical parameters
