Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
Specifications
Brand Name :
HOOHA
Model Number :
HH-500/630
Certification :
CCC,UL,RoHS, ISO,CE
Place of Origin :
Dongguan,China
MOQ :
1 set
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
10 sets per month
Delivery Time :
40 working days
Packaging Details :
Plastic Packing
Driven Type :
electric
Color :
Red
Single Wire Diameter :
1.5-5.09
Speed :
59m/min
Model :
HH-500
Bobbin :
PND500
Condition :
new
Warranty :
12 months
Description

High Speed Rigid Frame Stranding Machine For 35mm²- 400mm² Copper Wire,Aluminum Wire

Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²

Rigid stranding machine application :

Mainly used for copper and aluminum conductor cables twisted wire system fan pressed, pressed and drawn round conductor segment conductor strands twisted pre-pressed

Technical Parameter

Machine Type HH - 500 HH - 630
Single wire dia.

1.5-5.09(copper)

1.8-5.0(AL)

1.5-5.0(copper)

1.8-5.0(AL)
Max O.D 45 45
Stranded pitch 6 40-683 64-946
12 40-683 64-946
18 46-780 46-780
24 52-888 83-1226
Speed 6 86-150 69-162
12 86-140 69-162
18 75-135 61-143
24 66-1455 53-125
Speed 59 59
Bobbin PND500 PND630
Pay off bobbin PN1600-PN2500 PN1600-PN2500
Take up bobbin PN2500 PN2500-PN3150
Main motor 75KW 132KW

Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²

After-sales Service

1. Delivery date: 60 working days

2. Payment: TT or L/C

3. Packing: plastic packing, ensuring the goods' safety during the transportation.

4. Install and training service: 2 professional engineers who has over 5 years overseas installation and cable manufacturing training experience.

Electric Rigid Frame Cable Stranding Machine For Copper Wire Cores 35mm²- 400mm²
