Specifications
Brand Name :
LM
Model Number :
JMB-4000
Certification :
CE,ISO9001
Place of Origin :
China
MOQ :
1set
Price :
Depend on the situation
Payment Terms :
T/T
Supply Ability :
100sets per month
Delivery Time :
35days after received the payment by T/T
Description

5 gallons of bottled water drinking water filling machine production line

1, production capacity: 300 /h
2, gas source pressure: 0.45MPa
3, pump: 4 (Nan Fangbeng) stainless steel pump,
4, motor power: 4KW
5, filling head number: 2
6, gland head number: 2
7, washing station: two disinfection liquid washing, two way back washing, two pure water washing, a drop of water
8, appearance size: 3160 x 1500 x 1700 (mm)
9, gas consumption 0.45 cubic / minute
Two, the upper barrel device
1, production capacity: 300 /h
2, gas source pressure: 0.4MPa
3, transfer chain plate: 191.5 x 38.3 (engineering plastics)
4, motor power: 0.37KW
5, appearance size: 4000 x 500 x 1000 (mm)
6, gas consumption 0.45 cubic / minute
Three, finished barrel transfer
1, production capacity: 300 /h
2, motor power: 0.37KW
3, transfer chain plate: 191.5 x 38.3 (stainless steel)
4, appearance size: 5000 x 500 x 150 (mm)
5, height 200mm, the frame is made of stainless steel
Four, BS-2 brush bucket machine
1, production capacity: 300 /h
2, motor power: 1.1KW
3, brush: 1 sets
4, appearance size: 1000 x 1000 x 1250 (mm)
Five, pull cover machine
1, production capacity: 300 /h
2, gas source pressure: 0.5 MPa
3, appearance size: 600 x 500 x 1500 (mm)
4, gas consumption 0.45 cubic / minute
Six, shrink film machine (electric heating can be adjusted)
1, steam design pressure: 0.4MPa
2, rated working pressure: 0.4MPa
3, rated evaporation: 3.8kg/h
4, rated power: 3KW-6KW
5, the use of electric power: 380V
6, water capacity: 18kg
The shape of the device is: 500 x 350 x 1200 (mm)
Seven, lamp inspection (1)
1, detection ability: 300 barrel /h
2, power: 90W
3, appearance size: 800 x 300 x 1200 (mm)
Eight, inside the brush bucket machine (brush machine and filling machine)
1, production capacity of 300 barrels /h
2, gas source pressure: 0.5 Mpa
3, motor power: 250W
4, appearance size: 500 x 500 x 2000
5, gas consumption 0.45 cubic / minute
Nine, capping machine
1, the gland head number 1
2, gas source pressure 0.6MPa
3, gas consumption 0.45 cubic / minute
4, size: 500*500*1200 (mm)
Ten, sorting table
The size of 1200*200 (mm):
All stainless steel production
Eleven, transmission chain
Stainless steel chain plate (wide 193mm)
High 200mm, long 2000mm
All stainless steel production
Note:
1, empty drum transfer line height of 600mm, the transmission line is high 200mm.
2, pump minimum requirements: 0.8MPa, storage capacity of 1 cubic meters
3, total power consumption 20KW 4 site requirements (minimum): 20m*10m
