A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
Specifications
Brand Name :
hongcheng
Model Number :
1/2" TO 72 "
Certification :
PED、ABS、BV、DNV、GL、LR、SGS、IEI
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
T/T, L/C at sight
Supply Ability :
200,000 tons/year
Delivery Time :
7-15 work days
Packaging Details :
Plywood Cases or Pallets
Place of Origin: :
China
Standard :
ASTM A234. ASTM A420, ASTM A860
size :
1/8"-2", 1/2"-48", 1/2"-6", DN15-DN1200 1/2’’~48’’(Seamless);16’’~72’’(Welded)
Marking Requirements: :
As per your requirements
Surface treatment :
Surface treatment :sandblasting,shot blasting,pickling
Description

Alloy Steel Fittings Ansi B16.9 High-Pressure Alloy Steel Cap With A234 Wp91 And Forged Technique

ASTM B16.9 Butt Welded Pipe Fitting Cap Seamless Black painting or galvanized

Product : Steel pipe Cap

Standard: ASME B16.9, EN10235, DIN2617, JIS B2311, GOST 17378

Material: carbon steel ASTM A234 WPB, P235GH, P265GH, Stainless steel ASTM A403 WP304/304L, WP316/316L, WP321

Wall thickness: 2mm-60mm, SCH10,SCH20, SCH30, STD, SCH40, XS, SCH60, SCH80, SCH100, SCH120, SCH160, XXS

Size: 1/2' to 48"

Packing: seaworthy plywoon cases or pallet

A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure

A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure

A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure

DIMENSIONAL TOLERANCES – CAPS
For all fittings Caps
Nominal Pipe Size (NPS) Outside Ø at Bevel Inside Ø at End Wall Thickness
t / t1		 Overall Length E
1/2 a 2 1/2 1 0,8 Not 4
3 a 3 1/2 1 1,6 less 4
4 +2 -1 1,6 than 4
5 a 6 +3 -1 1,6 87,50% 7
8 2 1,6 of nominal 7
10 +4 -3 3,2 tickness 7
12 a 18 +4 -3 3,2 7
20 a 24 +6 -5 4,8 7
26 a 30 +7 -5 4,8 10
32 a 48 +7 -5 4,8 10

CAPS – Weights

WEIGHTS OF FITTINGS
NPS
inches		 CAPS
Sch.
5S		 Sch.
10S		 Sch.
40S		 Sch.
80S
1/2 0.04 0.04 0.05 0.05
3/4 0.05 0.05 0.06 0.08
1 0.09 0.09 0.13 0.17
1 1/4 0.11 0.11 0.15 0.18
1 1/2 0.15 0.15 0.20 0.22
2 0.17 0.17 0.25 0.30
2 1/2 0.25 0.25 0.45 0.50
3 0.40 0.40 0.70 0.90
4 0.60 0.60 1.20 1.60
5 1.00 1.00 1.90 2.70
6 1.40 1.40 2.90 4.30
8 2.50 2.50 5.10 7.60
10 3.90 3.90 9.00 12.0
12 6.50 6.50 13.5 17.5
14 8.00 8.00 16.0 20.5
16 14.5 14.5 20.5 26.0
18 17.0 17.0 26.0 34.0
20 18.0 18.0 32.0 43.0
24 26.0 26.0 46.0 60.0
Approximate weights in kg, density 8 kg/dm3

A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure

The reason why you Choose us

· ISO System

· TUV and BV Audited company .

· Industry experience over 50 years.

· Management Systems-Internal Software

· Finished Product Inventory-More Than 50000 Tons.

· Raw Material inventory -Over 80000 Mertic Tons.

· Shipment of goods -More than 50 countries worldwide.

· We have the most convenient transport and prompt delivery.

· We offer competitive price with best service .

· We have high technical production line with top quality products.

· We have win high reputation based on best quality products.

Choose Hongcheng ,Choose Top Guarantee

A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure

FAQ

Q. How long can make delivery?

A:For stock products, will make shipments in 5- 7 days after receiving deposit or receiving L/C; for products need new production for common materials, usually make shipments in 15-20 days; for products need new production for special and rare materials, usually need 30-40 days to make shipment.

Q:Can you provide the samples?

A:Samples can be provided with samples charge and courier fee by the buyer's side.

Q:Are the products in stock?

A:Yes.Most of our products are in stock.So we can prompt delivery.

Q:Can you accept customize?

A:Yes.It can be customized as per the customers' request.

Q:What about the quality?

A:According to the standard for production.And we can also accept the third-party

A234 Wp91 Alloy Steel Fittings Cap For Pipe Ansi B16.9 High Pressure
