Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
Specifications
Brand Name :
hongcheng
Model Number :
1/2" TO 24 "
Certification :
Pcoc, Reach, Iecee, Scoc, Epa, Gs
Place of Origin :
China
MOQ :
10PC
Price :
consult
Payment Terms :
L/C, D/P, T/T
Supply Ability :
2 Million Ton/Year
Delivery Time :
7-15 work days
Packaging Details :
Plywood Cases or Pallets
Certification : :
ASME, ANSI, DIN, JIS, BS, KS
Material : :
Alloy
Supply Ability: :
5000 Tons/Month
Wall thickness :
Sch5-Sch160 XXS,STD,XS, SGP
Angle :
45° 90 ° 180°,etc
Packaging Details : :
Pallet, Wooden Case
Description

Alloy Steel Elbow 90 A335 P11 P22 Wb36 P91 P92 Steel Pipe Elbow Astm A234 Wp11 Seamless Sch5s 90 Degree Lr Elbow

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow

Product Description

Type Elbow
Size Seamless 1/2" To 24" Welded To 72"(DN8~DN1000)
Wall thickness Sch5S-Sch160, XS,XXS(1.2mm~34mm)
Standards ANSI, ASTM,DIN, JIS, BS, ISO, GB, SH, AND HG etc
Material

Stainless Steel: ASTM A403 WP304, 304L, 310, 316, 316L, 321, 347, 904L

Alloy Steel:A335 p91 p91 p11 p5 p9 p22 s31803.s32750.S32760.

Temperature: ASTM A420 WPL 1, WPL 3, WPL 6
Surface treatment Sand Rolling, Sand Blasting ,Acid Cleaning.
Packing wooden case, pallet or as customers' requirement
Applications Petroleum,chemical,power,gas,metallurgy, shipbuilding, construction, etc
Min order 1 pieces
Delivery time 10 after receipt of advanced payment
Certificate ISO 9001-2008, CE
Productivity 50000 pieces per year

Product Parameters

NPS O.D.
D		 90° Long Rad Center to End
A		 45° Long Rad Center to End B 90° Center to End A 45° Center to End B
1/2 21.3 38 16
3/4 26.7 38 19 57 24
1 33.4 38 22 76 31
1¼ 42.2 48 25 95 39
1½ 48.3 57 29 114 47
2 60.3 76 35 152 63
2½ 73 95 44 190 79
3 88.9 114 51 229 95
3½ 101.6 133 57 267 111
4 114.3 152 64 305 127
5 141.3 190 79 381 157
6 168.3 229 95 457 189
8 219.1 305 127 610 252
10 273 381 159 762 316
12 323.8 457 190 914 378
14 355.6 533 222 1067 441
16 406.4 610 254 1219 505

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow

Seamless Steel Pipe Elbow , A335 P11 P22 Sch5s 90 Degree Lr Elbow
