Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
Specifications
Brand Name :
HongCheng
Model Number :
18-1219mm
Certification :
PED、ABS、BV、DNV、GL、LR、SGS、IEI
Place of Origin :
China
MOQ :
0.5Ton
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T
Supply Ability :
8000MT/Month
Delivery Time :
5-15 work days
Packaging Details :
Exporting package wooden box per customers requirement
Standards :
JIS AISI ASTM GB DIN CE
Surface :
Black Painted,PE coated,Galvanized.
Outside Diameter :
diameter 10.3 to 1219 mm
Section shape :
Round
Description :
alloy steel pipe, alloy seamless steel pipe, alloy welded pipe,seamless alloy steel pipe,alloy pipe,alloy steel tube
download :
Sch30 Sch40 STD Sch60 Sch80 XS Sch100 Sch160
Application Field: :
Power Plant, Chemical Plant, Shipyard, Petroleum, Sewage Treatment, Construction Industry, Etc.
Description

Alloy Seamless Steel Pipeastm A335 P91 Seamless Ferritic Alloy-Steel Pipe For High-Temperature Service

WE SPECIALIZED IN PRODUCING AND EXPORTING ALLOY STEEL SEAMLESS PIPES AND WELDED STEEL PIPES, BLACK AND HOT-DIPPED GALVANZIED, MEDIUM AND LOW PRESSURE BOILER TUBES, OIL CASING TUBING AND LINE PIPES, QUALIFY THE INTERNATIONAL STANDARD, SUCH AS API 5CT J55/55/N80/P110, API 5L/ASTM A53/A106 GRADE A/B, ASME A179/A192, DIN 2440/2448, BS1387, etc. SIZES AVAILABLE IN RANGE: 1/4"-48".

astm a335 p91 seamless pipe manufactuer ,p91 seamless steel pipe exporter, p91 seamless black pipes stockholder ,black seamless alloy pipe supplier in china

ASTM A335 Steel Ferritic Alloy Tubes Pipe for High-Temperature and Boilers

ASTM A335 Seamless ferritic and alloy steel pipe for high temperature service

Applications: for Boilers,Superheaters,Heat-Exchangers

Size range: O.D.:6-420mm W.T.:1-50mm L: according to customer requirement

Production details:

Standard ASTM, BS, JIS, DIN,GB
O.D. 1/2"-24" 10-610mm
W.T. SCH10--XXS 1.5-60mm
Length 5m-12m
End protection Plastic caps
Outside Coating Black painting, anti-corrosion oil, galvanized or as per required by customers
Packing Wrapped in bundles by steel strips/bulk
Delivery By sea container
Production Capacity 5000 tons per month
Delivery time 10-30days depend on your quantity
Tolorance OD :+1% / -1% WT: +12.5% / -10%
Application Transportation of oil,gas or fluid,Construction,Electricity,Machine building industy,Chemical industy,Petroleum,Traffic.
Main market Asia, India, Middle East, America, Europe

seamless steel pipe chemical composition:

Grade C Si Mn P S Cr Mo
P5 Max.0.15 Max.0.50 0.3-0.6 Max.0.025 Max.0.025 4--6 0.45-0.65
P11 0.05-0.15 0.5-1.0 0.3-0.6 Max.0.025 Max.0.025 1.0-1.5 0.44-0.65
P12 0.05-0.15 Max.0.50 0.3-0.61 Max.0.025 Max.0.025 0.8-1.25 0.44-0.65
P22 0.05-0.15 Max.0.50 0.3-0.6 Max.0.025 Max.0.025 1.9-2.6 0.87-1.13
Mechanical properties
Grade Yield point (Mpa) Tensile strength (Mpa) Elongation(%) Impact value(J)
P5 ≥205 ≥415 See table ≥35
P11 ≥205 ≥415 See table ≥35
P12 ≥220 ≥415 See table ≥35
P22 ≥205 ≥415 See table ≥35

Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service

Product Analysis

1 At the request of the purchaser, an analysis of two pipes from each lot shall be made by the manufacturer.

2 The results of these analyses shall be reported to the purchaser or the purchaser’s representative, and shall conform to the requirements

3 For grade P 91 the carbon content may vary for the product analysis by −0.01 % and +0.02 % from the specified range

4 If the analysis of one of the tests specified in 8.1 does not conform to the requirements specified in 6.1, an analysis of each billet or pipe from the same heat or lot may be made, and all billets or pipe conforming to the requirements shall be accepted.

ASTM specifications Boiler steel tube are used for high temperature service applications.

Danyal Pipelines can provide various grades of seamless steel pipes, such as A179, A192, A210, A213, A335 ,..etc

Standards Grades
Production Standards GB 5310 15MoG,15CrMoG,15CrMo,12Cr2MoG,12Cr1MoV,12Cr2MoWVTiB,10Cr9Mo1VNb
ASTM A179 A179
ASTM A192 A192
ASTM A210 Gr.A-1 , Gr.C
ASTM A213 T2, T5, T5b, T5c, T9, T11, T12, T17, T21, T22, T91, T92
ASTM A333 Gr.4, Gr.9, Gr.10, Gr.11
ASTM A334 Gr.9, Gr.11
ASTM A335 P1, P2, P5, P5b, P5c, P9, P11, P12, P15, P21, P22, P91,P92
ASTM A519 1330, 1335, 3140, 4140, 4130, 4337,....etc.
DIN 17175 15Mo3, 10CrMo9 10, 13CrMo44, 14Mov63
EN 10216-2 P195GH, P235GH, P265GH, 16Mo3, 10CrMo9-10
JIS-G3341 SCr 420TK, SCM 415TK, SCM 418TK, SCM 420TK, SCM 430TK, SCM 435TK, SCM 440TK
Size 1/2 inch to 28 inch & Wall thickness (1.5 ~30) mm
Packing Bundles with PE wrapping, Wooden case or customized

ASTM A192Chemical Composition:

Steel Grade C

Si

Max

 Mn P S
Steel Name Steel Number max max
A192 0.06-0.18 0.25 0.27 - 0.63 0.035 0.035

ASTM A192 Mechanical Property:

Steel Grade Tensile Strength Yield Strength Elongatinon
Steel grade Steel Number Min, MPA Min, MPA Min, %
A192 325 180 35

Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service

Specification

item value
Standard ASTM A106-2006, ASTM A53-2007, GB 5310-1995, GB/T 8162-1999, BS 1387, BS EN10025, JIS G3463-2006, JIS G3454-2007, JIS G3459-2004, DIN 1629/4, DIN 1626, DIN 1629/3
Grade ST37, ST45, ST52, ST35, A53(A,B), A106(B,C), A312, A335 P11, Q235, Q215, Q345, Q195, 15NiCuMoNb5, 16mn, 10#, 20#, 45#, STB35, STB42, STPG42, 15crmo, Cr5Mo, 12Cr2Mo, 13CrMo45, Cr2Mo, 15CrMoG, 12Cr1MoV, 12CrMo, 34CrMo4, 12CrMo195, 30CrMo, Cr5MoG, 10CRMO910, 13CrMo44, Cr9Mo, 35CRMO4, 12cr1movg, STBA25, STBA20, STBA22, STBA23, STBA24, STBA26, 15MnV, 09Mn2V, API J55, API L80, API K55, API P110, API N80, Cr17Ni8, 1Cr13Mn9Ni1N, STPA25, STPA24, STPA22, STPA26, STPA23, 15Mo3, 16Mo, 16Mo3, 10MoWVNb, 10Cr9Mo1VNb, A333, A335 P91, A269, A335 P9, A213, A210, A335 P92, A335 P1, A333 Gr6, A335 P5, A179-C, A192, A315, A335 P12, A209, A334, A178-C, A135-A, A335 P23, A214, A200, A250, A226, A369, A199
Thickness 1mm - 25mm
Section Shape Round
3mm - 50mm
Place of Origin China Hebei
Application Structure Pipe
Technique Cold Rolled
Certification API
Surface Treatment galvanized
Special Pipe Thick Wall Pipe
Alloy Or Not Non-Alloy
Tolerance ±1%
Type Seamless Steel Pipe
Processing Service Bending, Welding, Decoiling, Punching, Cutting
Product name Seamless Steel Pipe
Keyword Seamless Steel Pipe Tube
MOQ 1 Ton
Surface Black Painted
Shape Round Pipe Tube
Usage Construction Structure
Technology Hot Rolled Cold Rolled
Color Black as Customers' Requirement
Package Seaworthy Standard Package
Payment terms L/C T/T (30%DEPOSIT)

Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service

Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service

FAQ

Q: Can you accept a trial order only for several tons?

A: We can ship the regular specifications with LCL service.

Q: Do you provide free samples?

A: Yes, we could offer the sample for free, with the cost of freight paid by customer.

Q: How long is your delivery time?

A: Generally it is 7-10 days if goods are in stock or as your order requirement.

Q:How can you guarantee what I got will be good ?

A: We are factory with 100% pre delivery inspection which guarantee the quality.

Q: What is your terms of payment?

A: Payment<=8000USD, 100% in advance.

Payment>=8000USD, 30% T/T in advance ,balance before shippment. Or L/C at sight (For big order, LC at 30-90days can be acceptable)

Astm A335 P91 Ferritic Alloy Seamless Steel Pipe For High Temperature Service
