DX8466 Servo Cable Extrusion Tester 0-1.5KV Adjustable
DX8466 Servo Cable Extrusion Tester 0-1.5KV Adjustable
Specifications
Brand Name :
DAXIAN
Model Number :
DX8466
Certification :
GB12972
Place of Origin :
China
MOQ :
One set
Price :
Negotiation
Payment Terms :
L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash
Supply Ability :
15 sets per month
Delivery Time :
15 work days
Packaging Details :
Wooden case
Standard :
GB12972
Scope of application :
mainly applicable to the extrusion resistance of mining cables below UC-0.66KVT and UCP-1.14KV
Maximum measured load :
200N
Load resolution :
0.01N
Test voltage regulation :
0~1.5KV adjustable
Equipment weight :
60Kg
Power supply :
220V, 50Hz, 500W
Description

DX8466 Servo Cable Extrusion Tester

DX8466 Servo Cable Extrusion Tester 0-1.5KV Adjustable

1. Scope of application:

The performance of the servo cable extrusion resistance testing machine is mainly applicable to the extrusion resistance of mining cables below UC-0.66KVT and UCP-1.14KV.

2. Meet the standard: meet the requirements of the GB12972 test standard.

3. Technical parameters:

1. Maximum measured load: 200N.

2. Load resolution: 0.01N.

3. Maximun stroke: 600MM.

4. Test speed: 50~500MM/MIN continously adjustable.

5. Test voltage regulation: 0~1.5KV adjustable.

6. Automatic stop function: the specimen is short-circuited or broken, the power-off relay action, and the moving beam automatically stops (or automatically returns to the initial position).

7. It has program-controlled and mechanical two-level limit protection.

8. When the load exceeds the rated value by 3~5%, it will stop automatically.

9. Equipment weight: 60Kg.

10. Power supply: 220V, 50Hz, 500W.
